Specifications
Place of Origin :
made in China
Brand Name :
AIRERA
MOQ :
1 unit
Price :
520-30,000 USD
Packaging Details :
According to international standards
Delivery Time :
3-30 days
Payment Terms :
TT/LC
Supply Ability :
2,000-3,000 per month
Condition :
New Screw Air Compressor
Noise :
65-83dB
Cooling :
Air or Water Cooled
Power Supply :
220/380/415//440V 50/60Hz 3Ph
Size :
1540*920*1240mm
Cooling Method :
Air or Water Cooled
Colour :
Blue
Transmission Mode :
direct driven
Cooling Model :
Air cooling
Power Rating :
7.5 KW To 400 KW
Advanced Design :
Design in Germany
Start :
Delta Start
Driving System :
protection system
Inlet Pressure :
Atmospheric Pressure
Air end :
Rotorcomp
Description
EVO VSD Screw Air Compressor AGFD-VP Series
AGFD-VSD Series Air Screw Compressor
Historical well-known manufacturer producing quality screw compressors, oil-free compressors, and high-pressure compressors with ISO, TUV, and CE certifications. Features include competitive pricing, 5-year warranty, patented unique design, enhanced energy efficiency, and reliable compressor systems for all types of projects.
Why Choose EVO Series German Main Engine Compressor?
Advantages of our new EVO® technology:
  • New ROLLING PROFILE® - ultimate efficiency with reduced noise
  • Long life cycle due to increased bearing dimensions and wear-free ROLLING PROFILE®
  • Wide operating pressure range from 5 to 15 barg
  • High manufacturer assembling - "Made in Germany"
  • Quality assurance - bench test of every air end before leaving our factory
  • Easy application selection with our new ROTORCOMP® SIZING AIR Software
  • Highest flexibility for your package design
  • Suitable for all types of motors
EVO Air End Features
Ultimate efficiency and reduced noise through:
  • High volumetric output due to reduced internal leakage
  • Thermally optimized oil injection system
  • Improved suction port efficiency giving reduced internal losses
  • Optimized torque characteristics and reduced internal friction
  • Improved outlet port with lower pressure losses
  • Reduced noise and low vibration due to smooth rolling of the rotors with new ROLLING PROFILE®
  • Optimized outlet port
World-leading Rotorcomp Screw Air Compressor in unique design, better performance with competitive pricing, suitable for extremely demanding working environments with ISO, CE, TUV certifications.
5bar To 15bar VSD Screw Air Compressor Rotorcomp Air Compressor AGFD-VP Series
Advantages of EVO High-end Series Screw Compressor
  • World-leading Made in Germany Rotorcomp screw air end with 5-year warranty
  • Extraordinary cooling system, 20-30% better cooling performance than previous models, with easy maintenance access to cooler and cooling fan
  • Advanced Intelligent colorful touchable control system for simple and easy operation
  • Higher efficient energy-saving motor in SF.1.2.IP55, IE3 CE&MEPS to increase 15% efficiency
  • Unique driving guard system to increase the lifespan of driving system
  • Patented OPTI belt transmission - unique design ensures belt tensioning force by motor weight and start torque, with design service life up to 25,000 hours and transmission efficiency above 98%
  • Premium French Schneider white-color high-end contractor for durability in extreme environments

5bar To 15bar VSD Screw Air Compressor Rotorcomp Air Compressor AGFD-VP Series

Energy Efficiency Example
For example, a standard 55kW screw compressor delivers air at 70% loading and operates 5800 hours per year. Taking electricity cost of USD 0.15/kWH, the additional energy consumed compared with VSD compressor will be:
Energy consumed during unload operation assuming unload shaft power absorbed is 45% of full load amount: 30% unload times x loss during unload time = (45% x 55kW) x 5800 hour/year x USD 0.15 = USD 6,460/year.
Note: We can also choose ABB or Schneider converters according to requirements.
Technical Specifications
Model Air Flow (m³/min)* Power (kW) In/Outlet Noise dB(A)** Dimension L*W*H (mm) Weight (kg)
AGFD-5.5 VP 0.22-0.87 5.5 G1 69 900*750*900 255
AGFD-7.5 VP 0.30-1.20 7.5 G1 69 900*750*900 260
AGFD-11 VP 0.45-1.79 11 G1 70 950*800*1290 390
AGFD-15 VP 0.60-2.40 15 G1 70 950*800*1290 400
AGFD-20 VP 0.75-3.00 18.5 G1 71 1250*960*1300 755
AGFD-22 VP 0.88-3.51 22 G1 71 1250*960*1300 780
AGFD-30 VP 1.25-4.88 30 G1-1/4 71 1440*1006*1296 1250
AGFD-37 VP 1.46-5.83 37 G1-1/4 73 1440*1006*1296 1400
AGFD-45 VP 1.77-7.08 45 G1-1/4 75 1440*1006*1296 1450
AGFD-55 VP 2.33-9.32 55 G2 75 1600*1200*1650 1650
AGFD-75 VP 3.1-12.31 75 G2 75 1600*1200*1650 1800
AGFD-90 VP 4.2-16.45 90 G2 75 2000*1580*1790 2700
AGFD-110 VP 5.1-20.26 110 G2 78 2500*1700*1900 3100
AGFD-132 VP 5.8-23.08 132 G2 78 2500*1700*1900 3250
5bar To 15bar VSD Screw Air Compressor Rotorcomp Air Compressor AGFD-VP Series
Important Notes:
1. Parameters and color are designed according to customer needs, parameters are for reference only - final parameters as per technical drawings shall prevail
2. Cooling method (air/water), oil content, weight, and dimensions can be customized according to requirements - final specifications as per order and technical agreement
3. Frequency converters available as optional
4. 2 years warranty for compressor, 5 years warranty for air end
5. OEM & ODM service available, 220-450V/3/50-60Hz single & dual voltage customization accepted
6. ABB/Schneider/WEG inverters available as options
7. ISO, CE, TUV, GA, SGS certificates provided
