30KW Air-Cooling Oil Inject Screw Compressor
30KW Air-Cooling Oil Inject Screw Compressor
30KW Air-Cooling Oil Inject Screw Compressor
30KW Air-Cooling Oil Inject Screw Compressor
30KW Air-Cooling Oil Inject Screw Compressor
30KW Air-Cooling Oil Inject Screw Compressor
30KW Air-Cooling Oil Inject Screw Compressor
30KW Air-Cooling Oil Inject Screw Compressor
Specifications
Brand Name :
AIRERA
Model Number :
AGCD-30D C
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
TT/LC,Western Union,D/P,D/A
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Cooling air flow（m3/hr） :
9200
Application :
Medical, Pharmaceutical, Food Processing
Oil Content :
Oil inject
Working Pressure :
0.7-1.3Bar
Cooling type :
Air cooling
Driven type :
Direct driven
Description
AIRERA 30kW Air-Cooling Oil-Injected Screw Air Compressor
The AIRERA 30kW series is engineered to deliver a continuous, high-quality compressed air supply for demanding industrial environments. By combining our advanced screw technology with superior thermal management, we ensure your production line never misses a beat.
Key System Advantages
Oil separation system

Compressors up to 132 kW are equipped with external separators that can be changed in a simple spin-off/spin-on process. Larger units have an internal separator cartridge. Due to the excellent separation efficiency of the system as a whole, the compressors can be used in the pressure range of 5.0 to 15.0 bar. Special pressures on request.


30KW Air-Cooling Oil Inject Screw Compressor

Oil circuit

The amount of oil in the units is determined in such a way as to extend the oil change intervals (depending on ambient conditions). An oil level sensor is integrated as standard and is read by the controller. All the units in this series have a horizontal oil separation vessel in which the oil is separated from the compressed air highly efficiently at low speeds.


30KW Air-Cooling Oil Inject Screw Compressor

Drives and Electrics
The almost loss-free power transmission guarantees reliable, high-performance compressor operation. The regular maintenance requirement is reduced to lubrication of the motor. All the electronic components are brand products of leading manufacturers.
30KW Air-Cooling Oil Inject Screw Compressor
Technical Specifications - 30kW Air Cooling Compressor
ITEM UNIT MODEL AGCD-30
Free air delivery m³/min 5.2~3.6
Max. working pressure MPa 0.7~1.3
Compressor type
Oil inject screw compressor
Cooling type
Air cooling
Driven type
Direct driven
Inlet status - Temperature ℃ ≤45
Inlet status - Pressure MPa Atmospheric pressure
Inlet status - Relative humidity
≤90%
Noise Level dB(A) ≤72
Residual oil content ppm ≤2
Drive rotor speed rpm 2950
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m³/hr 9200
Control mode
Intelligent controller
Safety valve set pressure MPa 0.77 ~ 1.43
Lubricating oil volume L 30
Compressed air outlet connection
G1-1/2
Dimension - L mm 1400
Dimension - W mm 1000
Dimension - H mm 1400
Net Weight kg 715
Motor - Model
Y2180L1-2
Motor - Speed rpm 2950
Motor - Rated Power KW 30
Motor - Service factor
1.2
Motor - Efficiency
IP55
Motor - Startup mode
Y-Δ starting
Motor - Voltage V 380 (Special on request)
Motor - Frequency Hz 50 (Special on request)
Motor - Rated current A 56.9
Motor - Weight of motor kg 232
30KW Air-Cooling Oil Inject Screw CompressorFrequently Asked Questions
Q1: Why should I choose the 30kW Air-Cooling model over a Water-Cooling one?
A: Ease of Installation: Air-cooling systems don't require external cooling towers or complex piping, making them "plug-and-play." This is ideal for facilities with limited space or water resources. It also eliminates issues like limescale buildup and winter freezing risks.
Q2: Is the 30kW (40HP) capacity sufficient for my factory?
A: At 0.8Mpa, this model delivers approximately 5.0 - 5.5 m³/min. It is an "all-rounder" typically capable of supporting 3–5 automated production lines or a medium-sized CNC/spray-painting workshop.
