Semi Automatic Carton Sealing Machine I Type Carton Sealer High Speed Packing Machine
Semi Automatic Carton Sealing Machine I Type Carton Sealer High Speed Packing Machine
Specifications
Brand Name :
ZHIROBO
speed/min :
10-15(m/min)+6-10(m/min)
Machine Weight :
200+450kg
Price :
Negotiable
Certification :
VERIFICATION OF CONFORMITY
Machine size :
L1700mm×W900mm×H1510mm+L1950mm×W1150mm×H(Countertop height800)
Packaging Material :
Tape
Payment Terms :
T/T
Safetyfeatures :
Emergency stop button, safety guards
Warranty :
1 year
Place of Origin :
CHINA
Model Number :
ZRL-FC500+ZRL-FG500L
Delivery Time :
15-30 working days
Packaging Speed :
12 boxes/min at maximum
MOQ :
1 set
Description

Semi-Automatic I-Type Carton Sealing Machine

Basic use:

It is suitable for sealing and packaging of the same specifications. It is matched with the automatic packaging machine to realize automatic sealing, which greatly saves labor, reduces labor intensity and improves production efficiency.

Equipment advantages:

  • Designed for simultaneous batch processing of same-size cartons. Manual width and height adjustment is necessary during size replacement.
  • Equipped with automatic flap folding function, this linear carton sealer can cooperate with four-corner I-type sealing equipment to achieve full I-shaped carton sealing solution.
  • The tape mounting bracket adopts rigid precision structure, offering smooth movement and prolonged service cycle.
  • Besides independent operation, the machine can combine with unmanned automatic strapping machines and conveyors to set up automatic sealing & strapping packaging lines. Adhesive tape forms flat, stable and standardized sealing with good visual effect, and prevents carton tearing effectively.

Main Technical Parameters:

mode Carton Sealer ZRL-FC500 L-Type Semi-Automatic Side Sealer ZRL-FG500L
Voltage power AC200-240V 50/60HZ 0.2KW AC200-240V 50/60HZ 0.6KW
Package dimensions L(200-580)mm*W(120-480)mm*H(120-480)mm L(340-700)mm*W(200-500)mm*H(180-500)mm
working pressure 4kg/cm2 5kg/cm²
speed/min 10-15(m/min) 6-10(m/min)
Machine size L1700mm×W900mm×H1510mm L1950mm×W1150mm×H(Countertop height800)
Sealing tape width 48mm,60mm,70mm 48-72mm
net weight 200kg 450kg

Configuration Parameters:

Model Carton Sealer ZRL-FC500 L-Type Semi-Automatic Side Sealer ZRL-FG500L
Motor Taibang Taibang
PLC Control Customized
Contactor Schneider Schneider
Intermediate Relay Schneider
Push Button Switch APT Push Button Switch APT Push Button Switch
Pneumatic Cylinder Airtac Airtac

Equipment Layout:

Semi Automatic Carton Sealing Machine I Type Carton Sealer High Speed Packing Machine

Semi Automatic Carton Sealing Machine I Type Carton Sealer High Speed Packing Machine

Semi Automatic Carton Sealing Machine I Type Carton Sealer High Speed Packing Machine

Semi Automatic Carton Sealing Machine I Type Carton Sealer High Speed Packing Machine
