Desktop Scientific Research CT/3D
Equipment Features:
Small footprint, high scanning accuracy, and easy operation.
One-click full-process automation for data scanning, 3D reconstruction, and image analysis.
Compact structure with low space requirements.
Inspection Applications:
Small - sized PCBA boards.
Internal structure quality of semiconductor packaging products.
SMT solder joint quality, covering issues like cold solder joints, wetting, solder volume, offset, foreign objects, bridging, and pin presence.
Ray source parameter
| Type of ray tube | Closed tube X-ray source | ||
| Tube voltage range | T-130A:40-130 KV |
Detector parameter
| Detector type | Amorphous silicon flat panel detector | ||
| Pixel size | T-130A:100μm | ||
| Pixel matrix | T-130A:1536x1536 | ||
Equipment performance parameter
| Maximum placementt Sample size |
T-130A:diameter 400mm × height600mm | |||
| Maximum imaging area | T-130A:diameter 200mm × height300mm | |||
| JIMA card resolution | 3μm | |||
| Equipment weight | T-130A:1T | |||
| Equipment size | T-130A:1370mm × 850mm × 1770mm(Length×width× height) |
|||
| Imaging software system | Integrated scanning imaging software;3D image reconstruction software;3D image measurement and analysis software; Image database management software. |
|||
