3D X Ray Inspection System For 300mm Samples With 3μM Resolution
3D X Ray Inspection System For 300mm Samples With 3μM Resolution
Specifications
Brand Name :
WELLMAN
Model Number :
T-130
Certification :
CE FDA
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T
X-ray Tube Type :
Closed-tube X-ray source
Tube voltage range :
40-130 KV
Pixel matrix :
1536×1536
Equipment size :
2150mmx900mmx1750mm(Length × width × height)
Pixel size :
100 μm
Description

Basic Parameters


Ray Source Parameters

Type of ray tube Closed tube X-ray source
Tube voltage range (T-130) 40-130 KV

Detector Parameters

Detector type Amorphous silicon flat panel detector
Pixel size (T-130) 100μm
Pixel matrix (T-130) 1536x1536

Equipment Performance Parameters

Maximum sample size (T-130) Diameter: 300mm × Height: 320mm
Maximum imaging area (T-130) Diameter: 200mm × Height: 120mm
JIMA card resolution 3μm
Equipment weight (T-130) 1T
Equipment dimensions (T-130) 2150mm × 900mm × 1750mm (L×W×H)


Key Equipment Features
  • Compact structure with minimal space requirements
  • One-click full-process automation for data scanning, 3D reconstruction, and image analysis
  • High precision scanning capabilities
Inspection Applications
  • Small-sized PCBA boards
  • Internal structure quality of semiconductor packaging products
  • SMT solder joint quality inspection including:
    • Cold solder joints
    • Wetting issues
    • Solder volume analysis
    • Component offset detection
    • Foreign object identification
    • Bridging detection
    • Pin presence verification
Imaging Software System
  • Integrated scanning imaging software
  • 3D image reconstruction software
  • 3D image measurement and analysis software
  • Image database management software
