Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Sinotruk HOWO Foam Tank Fire Fighting Truck
Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Model NO. :
CLW5698MV
Volume :
＞10000L
Emission Standard :
Euro 3
Transmission Type :
Manual
Payload :
6tons
Fuel :
Diesel
Drive Wheel :
4×2
Horsepower :
150-250hp
Condition :
New
Logo :
as Per Customer's Request
Model of Fire Monitor :
Pl48 Fire Monitor
User Manual :
Yes
Truck Brand :
Dongfeng/Sinotruk HOWO/Foton/Shacman
Key Parts :
Pump, Fire Gun, High Pressure Pump
Usage :
Fire Fighting Truck, Emergency Rescue
Flow Rate of Fire Monitor :
60L/S 1.0MPa
Water Pump :
Chinese or International Brand
Extinguishant :
Water and Foam
Thickness of Water Tank :
4mm
Fire Fighting Pump :
Chinese or International Brand
Throw Range :
Water 55m, Foam 50m
Accessories :
as Per Customer's Request
Material :
Carbon Steel/Stainless Steel
Fire Fighting Monge :
Chinese or International Brand
Transport Package :
Bulk Ship, RO-RO
Specification :
6cbm, 6000liters, 6000L
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705309990
Production Capacity :
300 Units Per Month
MOQ :
1
Price :
15000-35000 per unit
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Description
Sinotruk HOWO 4x2 Fire Fighting Equipment 6000 Liter Foam Tank Fire Fighting Truck
Product Description

HOWO 4X2 fire fighting truck is composed with truck body and cabin,cabin is two rows,which can allow 6 persons.The front part of truck body is equipment room,middle is water tank and foam tank,rear is pump room.

To ensure good performance of fire trucks,howo fire truck is equipped with middle and low pressure fire pump CB20.10/30.6o with flow rate at 60L/S and Chengdu Wester fire monitor PL48(PM160)or PS60W(SG160).

Fire trucks are widely used in factory,terminal,oil&gas depot to insure emergency fire cases.

Specifications of HOWO 4X2 fire fighting truck
ModelParametersothers
Overall Dimension7660×2500×3460
GVW15560kg
Engine Model

Engine Power177kW
Wheelbase4500mm
Driving Type4X2
Max.speed90km/h
Emission Standard7790 mlEuro4
Passengers1+1+4
Fire pump rated flow60L/s@1.0Mpa;30L/s@2.0MpaVacuum pump
water monitor rated flow48-64L/sAdjustable
Water monitor rangeWater range≥60m,foam≥55m
Approach angle≥16°
Departure angle≥23°
Item ParametersParametersothers
1Water tank capacitywater3000Built-in type
Foam tank capacityfoam2000
2Fire pump modelCB20·10/30·60Shanghai rongshen


3


Fire pump performance


condition

Pressure1:1.0Mpa flow:60L/S
Pressure2:2.0Mpa flow:30L/S		Use vacuum pump to priming water
4the installation site of fire pumprear
5The quantity of fire pump water outlet6
6Pressure gauge0-1.6 Mpa, 0-2.5 MPa2.6 level
7Vacuum gauge-0.1- -1 MPa2.6 level



8



Water monitor
(PL48-64YZ)

waterFlow:
48- 64L/S		Range:60mShandong zhangqiu
foamRange:55m
Depression/Elevation angle-30-+70°
Turning angle 360°
9PTO ModelYTQ590K type full power sandwich , pneumatic
