Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Fuel :
Diesel
Condition :
New
Water Tank Capacity :
5t, 5ton, 5tons, 5mt
Transmission Type :
Manual
Logo :
as Per Customer's Request
Dry Powder Tank Capacity :
2tons, 2000kg, 2t, 2mt
Flow Rate of Fire Monitor :
60L/S 1.0MPa
Suction Depth :
Deeper Than 7m
Payload :
16tons
Extinguishing Agents :
Water, Foam
Accessories :
as Per Customer's Request
Origin :
Suizhou, China
Specification :
10000L, 10cbm, 10000liters, 10m3
Certification :
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
MOQ :
1
Price :
15000-35000 per unit
Model NO. :
CLW5252XGQ
Drive Wheel :
6×4
Fire Monitor Rangemonitor :
Water More Than 65meters, Foam More Than 60meter
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
HS Code :
8705309990
Volume :
7001-10000L
Trademark :
CLW
Emission Standard :
Euro 2
Horsepower :
251-350hp
Model of Fire Pump :
CB20.10/30.60 Fire Pump
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Engine Type :
Wd615.47, 371HP
Production Capacity :
300 Units Per Month
Model of Fire Monitor :
Pl48 Fire Monitor
Type of Fire Pump :
Low Pressure Centrifugal Pump
Description
HOWO Emergency Rescue 10Tons Water Dry Powder Foam Combination fire fighting truck

Dry powder Fire Fighting Truck, which is also called water fire engine,water foam fire truck,fire fighting equipment, fire appliance truck, foam fire tanker, water foam pumper, light rescue apparatus, fire fighting vehicle, foam discharging truck, foam tanker fire truck is a special vehicle designed primarily for fire fighting operations and to extinguish fire efficiently to prevent fire spread, reducing the loss caused by fire maximumly.

dry powder fire fighting truck can be divided into several types:

  • According to vehicle size, there are mini fire fighting truck,light fire fighting truck,medium fire fighting truck, heavy-duty fire fighting truck.
  • According to chassis drive type, there are 4X2 or 6-wheel fire fighting truck, 6X4 or 10-wheel fire fighting truck, 8X4 12-wheel fire fighting truck and off-road type 4X4, 6X6 fire fighting truck for use.
  • According to chassis brand, there are fire fighting truck, Dongfeng fire fighting truck, Foton fire fighting truck, FAW fight fighting truck, Shacman fire fighting truck, sinotruk fire fighting truck, Mercedes fire fighting truck, MAN fire fighting truck, fire fighting truck and so on.
  • According to fire extinguishant,there are water tank fire fighting truck, dry powder fire fighting truck, water/foam fire fighting truck
  • There are also fire rescue truck with special purpose as follows,
    • Foam supply fire truck;
    • Compressed air supply fire fighting truck;
    • Water tower fire truck ;
    • Earthquake rescue fire truck;

Features of howo 10ton dry powder fire truck :

  • Optional for different siz,strong enough for all road conditions.
  • powderful engin; reliable performance, no overhaul within 100,000 km.
  • Nice shape, rational structure.
  • High quality fire pump
  • Massive, durable, long service life.
Spec. of HOWO Emergency Rescue 10Tons Water Dry Powder Foam Combination fire fighting truck
Model Parameters others
Overall Dimension 9965*2500*3750mm
GVW 26100kg
Engine Model WD615.47
Engine Power 273kW
Wheelbase 4600+1350mm
Driving Type 6×4
Max.speed 102km/h
Emission Standard 9726ml/kW Euro4
Fire pump rated flow 60L/s@1.0Mpa, 30L/s@2.0Mpa Vacuum pump
water monitor rated flow 48-64L/s@1.0-1.2Mpa (ajustable) Straight stream/spray/mist spray
Water monitor range Water range≥65m,Foam≥60m
Passengers 2+4
Approach angle ≥16°
Departure angle ≥19°
Item Parameters Parameters others


1


Tank capacity

 water ≥5000
Foam ≥3000
Dry powder ≥2000kg
2 Fire pump model CB20.10/30.60 Shanghai rongshen
3 Fire pump performance Pressure 1:1.0Mpa flow:60L/S
Pressure 2: 2.0Mpa flow:30L/S		 Use vacuum pump to priming water
4 the installation site of fire pump rear
5 The quantity of fire pump water outlet 6

Dry powder tank pressure 0.5Mpa~1.7Mpa
6 Pressure gauge 0-2.5 MPa 2.6 level
7 Vacuum gauge -0.1- -1 MPa 2.6 level



8



Water monitor
(PL48-64)


Injection pressure

 water:≥65m
Foam: ≥60m		 Zhangqiu
1.0~1.2Mpa
Depression/Elevation angle -15-+75°
Turning angle 340°
9 Foam proportioner 3%-5%
10 PTO Model YTQ800F type full power sandwich , pneumatic Sinotruk
