Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Dongfeng 4X2 4000liters Water Tank Fire Fighting Truck Vehicle
Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Certification :
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
MOQ :
1
Price :
15000-35000 per unit
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Model NO. :
CLW5547nv
Volume :
＞10000L
Emission Standard :
Euro 3
Transmission Type :
Manual
Payload :
6t
Fuel :
Diesel
Drive Wheel :
4×2
Horsepower :
150-250hp
Condition :
New
Extinguishing Agents :
Water, Foam
Accessories :
as Per Customer's Request
Flow Rate of Fire Monitor :
60L/S 1.0MPa
Material :
Carbon Steel/Stainless Steel
Fire Fighting Mongemonitor :
Chinese or International Brand
Logo :
as Per Customer's Request
Truck Brand :
Dongfeng/Sinotruk HOWO/Foton/Shacman
User Manual :
Yes
Key Parts :
Pump, Fire Gun, High Pressure Pump
Usage :
Fire Fighting Truck, Emergency Rescue
Water Pump :
Chinese or International Brand
Fire Fighting Pump :
Chinese or International Brand
Throw Range :
Water 55m, Foam 50m
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Specification :
6cbm, 6000liters, 6000L
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705309990
Production Capacity :
300 Units Per Month
Description
Dongfeng 4X2 4000Liters Water Tank Fire Fighting Truck Vehicle Rescue Fire Engine Truck
Product Description

1.Dongfeng 4X2 fire fighting truck is composed with truck body and cabin,cabin is two rows,which can allow 6 persons.The front part of truck body is equipment room,middle is water tank and foam tank,rear is pump room.

2) To ensure good performance of fire trucks,howo fire truck is equipped with middle and low pressure fire pump CB20.10/30.6o with flow rate at 60L/S and Chengdu Wester fire monitor PL48(PM160)or PS60W(SG160).

3) Fire trucks are widely used in factory,terminal,oil&gas depot to insure emergency fire cases.

Model Parameters others
Overall Dimension 7660×2500×3460
GVW 15560kg
Engine Model

Engine Power 177kW
Wheelbase 4500mm
Driving Type 4X2
Max.speed 90km/h
Emission Standard 7790 ml Euro4
Passengers 1+1+4
Fire pump rated flow 60L/s@1.0Mpa;30L/s@2.0Mpa Vacuum pump
water monitor rated flow 48-64L/s Adjustable
Water monitor range Water range≥60m,foam≥55m
Approach angle ≥16°
Departure angle ≥23°
Item Parameters Parameters others


1

 Water tank capacity water 3000 Built-in type
Foam tank capacity foam 2000
2 Fire pump model CB20·10/30·60 Shanghai rongshen


3


Fire pump performance


condition

 Pressure1:1.0Mpa flow:60L/S
Pressure2:2.0Mpa flow:30L/S


Use vacuum pump to priming water
4 the installation site of fire pump rear
5 The quantity of fire pump water outlet 6
6 Pressure gauge 0-1.6 Mpa, 0-2.5 MPa 2.6 level
7 Vacuum gauge -0.1- -1 MPa 2.6 level



8



Water monitor
(PL48-64YZ)

 water Flow:
48- 64L/S		 Range:60m Shandong zhangqiu
foam Range:55m
Depression/Elevation angle -30-+70°
Turning angle 360°
9 PTO Model YTQ590K type full power sandwich , pneumatic
