Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Dongfeng Fire Fighting Truck 5ton Mini Fire Rescue Fire Truck 6 Wheelers
Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Emission Standard :
Euro 3
Drive Wheel :
4×2
Seats :
6
Payload :
5ton
Origin :
Suizhou, China
Specification :
6185x1980x2760mm
Transmission Type :
Manual
Name :
Dongfeng Fire Fighting Truck
Horsepower :
＜150hp
Certification :
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
MOQ :
1
Price :
15000-35000 per unit
Max Fire Fighting Distance :
>50m
Volume :
3001-5000L
Fire Monitor :
PS20, 1200L/M
Max Water Tank :
4000L
Transport Package :
Bulk Ship, RO-RO
Fuel :
Diesel
Driving Direction :
LHD RHD
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Max Foam Tank :
500L or Not Have
Trademark :
CLW
Model NO. :
VLTDF5060
Water Pump :
CB10/20, 1200L/M
HS Code :
87059099
Condition :
New
Delivery Time :
Within 60 Days
Description

Chinese Mini Fire Rescue Fire Truck Dongfeng 6 Wheelers 2500L Capacity Small Fire Fighting Truck

CHASSIS PARAMETER
Overall Dimension: (mm) 6260x1900x2750
Fuel Type: Diesel, Euro III
Drive Type: 4*2, Right Hand Driving
Engine CY4F90-30
Power: 90HP
Spring Leaf Quantity: 8/9+5
Tyre Size: 7.00-16
Tyre Quantity: 6, (front 2, rear 4)
Total Mass:(kg) 5495
Curb Mass:(kg) 3870
F/R Axle Load(kg): 2470/3025
Front/Rear Suspension: (mm) 1032/1928
Approach/Departure(°): 19/12
Max Speed(km/h): 90
Wheel Base(mm): 3300
Passenger in cab 2+3
Watering system Performance
Water tanker: 2500L
Normal pressure pump: CB10/20
Flow Pressure: 20L/S/1.0Mpa
PL20 Fire Pump Flow: 20L/S
Pressure: 1.0MPa
Fire distance (water): ≥48m
Fire distance (foam): ≥45m
Accessories as attachment required
Equipment List
Fire truck manual 1
Chassis use manual 1
Fire pump use munual 1
Suction pipe KD150x4m 1
Water filter FLF100 1
Water knockout drum FII80/65x2-1.6 1
Water collectormanifold JII100/65x2-1.0 1
Hose 13-65-20 8
Hose adapter KJ65/80 2
Hose gaiter DT-SB 4
Hose strap 4
Overgroud hydrant wrench QT-SD1,400 1
Underground hydrant wrench 860 1
Suction wrench FS100 2
Dc switch water gun QZG3.5/7.5; 65 1
Dc switch water gun QZK3.5/7.5; 65 1
Fire extinguisher 3 kg/ABC 1
Hatchet for firefighters GF-285 , 390 1
Rubber hammer 1
Rechargeable portable lighting 1
