Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Transmission Type :
Manual
Production Capacity :
500unit/Month
Control Position :
in Bucket & Tool Box
Safety Feature :
Auto Lock
Emission Standard :
Euro3, Euro4, Euro5
Platform Rated Load :
200kg
Condition :
New
Drive Wheel :
4x2
Model NO. :
CLW5125K6MLQ
Arm Type :
Telescopic Arm, Knuckle Arm
Specification :
16-20m
Hoesrpower :
156HP
Hook Loading :
1000kg
Optional Hook :
Equipment Lifting
Riggers :
4units
Truck Brand :
Dongfeng, Foton, etc.
Transport Package :
Naked Package
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Max. Working Range :
8m
Name :
Lift Platform Truck
Fuel :
Diesel
Color and Logo :
Customized
HS Code :
8701909990
Delivery Time :
30 Days
Trademark :
CLW
Origin :
Suizhou, China
Payload :
8ton
Warranty Time :
1 Year
MOQ :
1
Price :
15000-35000 per unit
Working Height :
12meter, 14meter, 16meters
Boom Turn Around Angle :
360 Degree
Description
Product Description

Description:

  1. Electronical controlled Lifting Arm with Doulbe Side Balance Vavle.
  2. Four Hydraulic Cylinders Control Leg to ensure the Truck Balance.
  3. 360 degree Rotation Arms.
  4. Arm and H leg Automatic Locking System to secure safety handling.
Aeria lPlatform JMC (14-16M)

General

 Vehicle Brand CLW
Chassis Brand JMC
Overall Dimension 7480x2150x3100mm
GWW/Kerb Weight 4,490kg/13,850kg
Cab Cab Capacity 2+3 persons allowed
Air Conditioner With air conditioner

Engine

 Fuel Type: Diesel
Engine Brand JAC engine, HFC4DA
Power 92Ps(68KW)
Displacement 2771ml
Emission Standard EuroII, EuroII or Euro IV

Chassis

 Drive Type 4X2,left hand drive
Transmission 5-forward gears& 1reverse
Wheelbase/No.of axle 3360mm/2
Tyre Specification 7.00R16
Tyre Number 6 tyres and 1 spare tyre
Max Speed 95km/h
Paint Metallicpaint

Superstructure

 Cage Rated Capacity 200kg
Working Height 14-16M
Outriggers 4pcs,H-type;Hydraulically extend and retract
Slewing 360°continuous rotation with base turntable
Control Control both on the ground and in the cage
Emergency electrical/manual pump is equipped to operate the equipment in
case of engine failure.
Emergency stop switches at base and operator'scage.
Optional Insulated cage;Cargobox;Hoist hook with cables can be equipped fo rthe
function of a crane.
