Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Pickup Aerial Platform Truck 16m 18m 20m 22m 24m 26m High Altitude Operation Truck
Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Lifting Height :
16meter, 18meters, 20meters, 22meters
Drive Wheel :
4x2
Hoesrpower :
150-250hp
Fuel :
Diesel
Working Height in Max Working Radius :
15meters
Trademark :
CLW
Produce Name :
High Altitude Operation Truck
Bucket Size :
1000X650X1200mm
Transmission Type :
Manual
Payload :
5-15ton
Condition :
New
Arm Type :
Folded or Telescopic
Max Hook Height :
9.5 Meters
Origin :
Suizhou, China
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Name :
Aerial Platform Truck
Transport Package :
Naked Package
Max Working Radius :
8.0meters
Specification :
18meters, 20meters, 22meters
Working Radius in Max Height :
3meters
Production Capacity :
500unit/Month
Model NO. :
CLW5089GKZ
Hook Weight :
800kg
Optional Brand :
Dongfeng
Rear Legs :
H Shape
HS Code :
8705909990
MOQ :
1
Price :
15000-35000 per unit
Bucket Loading Weight :
200kg
Max Working Height :
22meters
Emission Standard :
Euro 3
Front Legs :
H Shape
Turning Angle :
360 Degree
Description
16m 18m 20m 22m 24m 26m Aerial Working Bucket Truck Mounted High-altitude Work Platform 12/14/16/18/20/22/24/26 Meters Cherry Pickup aerial platformTruck
  • Automatic Bucket Balance System, Bucket will be Stayed in Balance Level in All Working Time.
  • The Stretching Angle Up to 80°, which will be Easier to Handle in All Time.
  • Full Computer Control System with Danger Waring System.
  • LCD Screen in Both the Bucket and Truck to Display the Working Status.
  • Rectangular Shape Arms to Increase the Arm Strength.
  • V Shape Leg, H Shape Leg can Adapted to Different Road Condition Increasing the Stability.
Product Specification
Telescopic Skylift Bucket Truck 22m ~24Meter
Overall dimensions7410x2210x3550 mm
Gross vehicle weight8950kg
Wheel base3800 mm
F/R track base1110/1990mm
Approach/departure angle21/12°
CabinDongfeng Single Row Cabin, 2 Passenger Allowed,
EngineDiesel Engine B140 33, 4 Stroke, 4 Cylinder in line, Turbocharged, Inter cooling
Displacement/ HP3760CC / 141HP
Max speed90 km/h
Tire specification7.60 - 16, 6 Pieces with 1 Spare
Number of axles2




Bucket

Max. work height: 23 meters
Max. bucket floor height: 22meters
Max. work radius: 10 meters
Rated load: 200kg
Dimension (L×W×H) 1000×650×1200 (mm)


Boom

Type Four-section telescopic synchronously
Rotation angle 360°
Elevation angle -12°~80°
OutriggersType: H
4000x4000mm







Major Feature

Outriggercomputer controlled system, one key to stretch out & balance the level of the truck
BalancingAutomatically Balancing system with Tilting Angle Sensor & level detector
Getting on & off LockComputer control system,
Telescopic Arm ControlControlling system in the bucket, with manual control.
Platform Control systemLED Screen Display with Button control
Range ControlLarge Angle Sensor to Detect the Arm Length & Rotation Range
Walkie-TalkieIncluded
