3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
Specifications
Origin :
Suizhou, China
Model NO. :
CLW3040Z1DPT
Horsepower :
150-250hp
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Place of Origin :
CHINA
Brand Name :
CLW
MOQ :
1
Price :
15000-35000 per unit
Tire Certification :
ECE, GCC, ISO, DOT
Dumping Type :
Front Lifting Style
Engine Capacity :
＜4L
Specification :
5995x2055x2360
Production Capacity :
500 Unit/Month
Seats :
3 Seats
Trademark :
CLW
Name :
Tipper Dump Truck
Tire Design :
Bias
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Condition :
New
HS Code :
8704210000
Emission Standard :
Euro 3
Load Capacity :
1-10t
Drive Wheel :
4×2
Description
Truck Specification
truck model CLW3040Z1
Cab Dongfeng single row cab, with power steering. without a/c
Driving Type 4*2 Left hand driving
Max Speed (km/h) 90
Overall dimension(mm) 5995*2055*2360
GVW(kg) 4495
Mass in working order (kg) 2715
Wheelbase(mm) 3300
F/R track base (mm) 1543/1540
F/R overhang (mm) 1075/1475
Approach/Departure Angel 23/18
Tire 7.50-16 (6+1)
Clutch Single-plate dry diaphragm spring clutch
Steering Hydraulic steering with power assistance
Gear box 5-speed font +1 rear reverse
Bridge Front axle 2T
Rear axle 4T

Enging

 Model CY4102-C3F
Fuel Type Diesel fuel
Type Water-cooled, four-stroke,, direct injection, turbocharged
Exhaust(ml) 3856
Max output power/rotate speed (hp /rpm ) 95/3200
Braking system Service Brake Compressed air brake
Park Brake Spring energy
Auxiliary brake engine exhaust brake
Eletric system 24v
Upper-Body specification
Dump box dimension (L*W*H)(mm) 4200*1900*550
Dump box material Carbon steel
Dump box thickness (mm) bottom/side 4/3
Hydraulic cylinder Middle-placed T-Shape cylinder
Dump box color According to customer's requirement

3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck

3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck

3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck

3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck

3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck

3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck

3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
