Specifications
Emission Standard :
Euro 2
Tire Design :
Tubeless
Usage :
Transportation of Mineral, Stone, Sand, Ans So on.
Origin :
Suizhou, China
Delivery Time :
35 Days
Warrenty :
1 Year
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Drive Wheel :
6×4
Color :
as Customer's Request
Seats :
≤5
Tire :
Radial Tire 12.00r20 or Tubeless Tire 12r22.5
Specification :
8300x2500x3200mm
Place of Origin :
CHINA
Brand Name :
CLW
Load Capacity :
41-50t
HS Code :
8704230090
Engine Capacity :
＞8L
MOQ :
1
Price :
15000-35000 per unit
Cabin :
3 Person with A/C
Testing :
Products Inspction Before Shipment
Dumping Type :
Middle and Front Tipping
Horsepower :
251-350hp
Condition :
New
Oil Cylinder Brand :
International Brand Hyva or Chinese Brand
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Engine :
336HP, 371HP, 380HP
Name :
Tipper Dump Truck
Tire Certification :
ISO
Thickness of The Box :
Side 8mm, Bottom 10mm
Production Capacity :
500pieces/Month
Model NO. :
CLW3257HD
Lifting Type :
Middle Lifting, Front Lifting
Dump Material :
Carbon Steel Q235 or Q345 or Haxdox 450
Trademark :
CLW
Wheelbase :
3775+1440mm, 3800+1350mm, 4300+1400mm
Description
Product description
China 30 Tons 35 Tons HOWO Dump Tipper Truck Minery Construction Mining Transportation Dumping/Tipping truck
Product description:
  • Dump truck brand:SINOTRUK HOWO,CAMC,SHACMAN,JAC,NORTH-BENZ,FOTON...
  • Tipping Model:Front-tipping,middle tipping dump truck,HYVA or Chinese brand hydraulic oil cylinder brand
  • High tensile steel for dumper materia,4mm,6mm,8mm, 10mm oer as per client's request and purpose.
  • Used in construction site for transportation of mineral,stone,sand and so on.
Specification of dump truck:
ConditionNew condition/Left hand drive/6x4












Chassis

BrandSINOTRUK
ModelHOWO
Curb weight(kg)12100 kg
Loading weight30000 kg
Axle loading(Front/Rear)(kg)9000/16000/16000kg
Wheelbase(mm)3800+1350 mm
Dimensions(mm)8300*2496*3450 mm
Wheel track (front/rear) (mm)2036/1860/1860 mm
Front/Rear overhang(mm)1500/1650 mm
Approach/Departure angle(°)19/17
Max. driving speed(km/h)95 km/h
ClutchSingle-plate dry diaphragm spring clutch
Fuel tank volume(L)300 L
Brakes

Air brake

Steering GearZF8118


Wheel & types

Rims8.25-20, 10 hole-steel
Quantity10pcs with one spare tire
Specifications12R22.5
TransmissionModel HW19710, 10 Forwards and 2 reverses, with PTO
CabinHW70, HW76






Engine

BrandSINOTRUK HOWO
ModelWD615.47
Fuel typeDiesel
Displacement(ml)9726 ml
Power(kw)273 kw
Horsepower(HP)371HP
Cylinder number6
Emission standardEuro 2
Description4 stroke direct injection diesel engine
6 cylinder in-line with cooling, turbo-charging & intercooling






Upper

TypeU type or rectangle type
Size(mm)5400*2300*1300 mm
Max. Loading weight(kg)30tons~35 tons
Button Thickness(mm)6.0 mm
Side plate Thickness(mm)4.0 mm
MaterialQ235 Carbon steel/ Har-dox 450/ NM 450
Tipping typeMiddle Tipping
Oil cylinder brandChina local brand
Oil cylinder size(mm)220 mm
Remarks1. Color is optional
