Specifications
Warrenty :
1 Year
Production Capacity :
500pieces/Month
Engine :
260HP, 336HP, 371HP
Tire :
Radial Tire 12.00r20 or Tubeless Tire 12r22.5
Place of Origin :
CHINA
Brand Name :
CLW
Tire Certification :
ECE, GCC, ISO
Dumping Type :
Front Lifting Style
Condition :
New
MOQ :
1
Price :
15000-35000 per unit
Dump Material :
Carbon Steel Q235 or Q345
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Load Capacity :
41-50t
Emission Standard :
Euro 2
Seats :
≤5
Trademark :
CLW
Origin :
Suizhou, China
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Horsepower :
351-450hp
Tire Design :
Tubeless
Lifting Type :
Front Lifting, Middle Lifting
Oil Cylinder Brand :
International Brand Hyva or Chinese Brand
Model NO. :
CLW3312WYTU
Drive Wheel :
8×4
Engine Capacity :
＞8L
Thickness of The Box :
Side 8mm, Bottom 10mm
Usage :
Transportations of Mineral, Stone, Sand, and So on
Color :
as Customer's Request
Cabin :
3 Pesons with A/C
Specification :
20tons
Name :
Tipper Dump Truck
Delivery Time :
35 Days
Wheelbase :
1800+3575+1400mm
HS Code :
8705909090
Description

Product description

Shacman tipper truck 12 wheeles dump body 40ton 50ton dump tipper truck

Product description:

  • Dump truck brand: SINOTRUK HOWO, CAMC, SHACMAN, JAC, NORTH-BENZ, FOTON, etc.
  • Tipping Model of dump truck: Front-tipping, Middle-tipping.
  • Hydraulic oil cylinder brand of dump truck: International brand HYVA or Chinese famous brand.
  • High tensile steel for dumper materia of dump truck: 4mm, 6mm, 8mm,10mm or as per customer's request.
  • Used in Construction or Mineral site for Transportation of mineral, stone, sand, garbage and so on.

Specification of dump truck:

ITEM PARAMETERS
Brand SHACMAN
Model F2000
Product Dump truck
Cabin Left hand drive, without air conditioning
GVW(kg) 31000
Curb weight(kg) 14600
Front axle 9.5T man technology
Rear axle 16Ton man casting axle, final ratio 4.769
Wheelbase(mm) 1800+3575+1400
Overall dimensions(mm) 10329×2490×3450
F/R suspension(mm) 1525/2054
F/R track base(mm) 1939/1939, 1850/1850
Approach/departure angle(°) 28/20
Max speed(km/h) 85
Clutch 430 diaphragm type
Fuel tank volume 400L(alloy)
Brakes Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake
Steering gear Power steering, hydraulic steering with power assistance
Tire quanity 12 pcs with 1 spare tire
Tire specification 12.22R20
Transmission 9 speed forwarder, with 1 reverse
Cab With air conditioning and a sleeper
Traction system 8×4
Number of axles 4
Engine model WP12.430E201(WEICHAI)
Displacement 11.596L
Power 283kw/385hp
Emission standard EURO 2
Gearbox 12JSD200T-B+QH50, FAST gearbox
Fuel type Diesel
Max torque 2060N.m
Cylinder number 6
Electric system(V) 24
Operation control sysytem Electrically hydraulic control

Dump body

 Size: 7400×2300×1500
Max loading weight: 40ons
Material: carbon steel Q235
Side thickness: 6mm, bottom thickness: 8mm.
Hyva front tipping;
China famous oil cylinder cylinder
Color is optional for customer's request
