China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
China Dongfeng 18m 20m 22m 24m 25m Hydraulic Aerial Manlift High Altitude Working Platform Truck Aerial Platform Truck
Specifications
Payload :
5-15ton
Bucket Size :
1000X650X1200mm
Turning Angle :
360 Degree
Max Working Radius :
8.0meters
Specification :
20m, 22m, 24meters, 26m
Front Legs :
H Shape
Lifting Height :
14m, 16m, 18m, 20m, 22m
Place of Origin :
CHINA
Brand Name :
CLW
Hoesrpower :
90HP - 190HP
Working Radius in Max Height :
3meters
Arm Type :
Folded or Telescopic
Transmission Type :
Manual
Emission Standard :
Euro 3
Origin :
Suizhou, China
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Drive Wheel :
4x2
Produce Name :
High Altitude Operation Truck
Optional Brand :
Dongfeng, Forland, Sinotruk FAW
Working Height in Max Working Radius :
10.1meters
Production Capacity :
500unit/Month
Condition :
New
Max Working Height :
24meters
Trademark :
CLW
Fuel :
Diesel
Bucket Loading Weight :
200kg
HS Code :
8705909990
MOQ :
1
Price :
15000-35000 per unit
Name :
Aerial Platform Truck
Model NO. :
CLW5089GKZ
Hook Weight :
800kg
Rear Legs :
H Shape
Max Hook Height :
8.1meters
Transport Package :
Naked, RO-RO, Bulk, Container
Description

China Dongfeng 24m 25m Hydraulic Aerial Manlift Work Platform Truck

Product Description

  • Automatic Bucket Balance System, Bucket will be Stayed in Balance Level in All Working Time.
  • The Stretching Angle Up to 80°, which will be Easier to Handle in All Time.
  • Full Computer Control System with Danger Waring System.
  • LCD Screen in Both the Bucket and Truck to Display the Working Status.
  • Rectangular Shape Arms to Increase the Arm Strength.
  • V Shape Leg, H Shape Leg can Adapted to Different Road Condition Increasing the Stability.

Product Description

24Meter Aerail Platform Truck
Overall dimensions 8450×2050×3050 mm
Maximum Height 24 meters
Maximum operation radius 8.0 meters
Gross vehicle weight 6705 kg
Mass in working order 6380 kg
Wheel base 4200 mm
F/R track base 1015/2280mm
Approach/departure angle 24/10°
Cabin Dongfeng, Right/Left Hand Driving, with A/C.
Engine Diesel Engine B140 33, 4 Stroke, 4 Cylinder in line, Turbocharged, Inter cooling
Displacement/ HP 3900 Liter / 140HP
Max speed 90 km/h
Tire specification 900R20
Traction system 4x2
Number of axles 2





Equipment

1. Max operation height:18m

(including 1.7meter person height, net height is 16.3meter),

2. Max operation radius≤7.9m,

3. Max working platform height≤16.3m,

4. Working platform rating loading≤200kg,

5. Working platform rating allowable passengers=2,

6. Working platform dimension:1100*570*1000mm,

7. 360°turning(left or right), 4 H-shape legs.

8.The cage be operated both in the air and on the earth
