Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Specifications
Condition :
New
Grinding Length(mm) :
600
Surface Roughness(μm) :
0.32 μm
Table Size(mm) :
630x1250mm
Table Travel (X) (mm) :
550
Table Travel (Y) (mm) :
1200
Year :
2024
Place of Origin :
Henan, China
Brand Name :
TIMEWAY
Dimension(L*W*H) :
4340x2300x2500mm
Weight (KG) :
6500
Power (kW) :
7.5
Warranty :
1 Year
Key Selling Points :
Competitive Price
Showroom Location :
India, Indonesia, Germany, Mexico, Australia, Viet Nam, Canada, Malaysia, Philippines, Colombia, Thailand, Italy, Chile, Algeria, United States
Marketing Type :
New Product 2024
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Motor, Engine
Applicable Industries :
Farms, Manufacturing Plant, Energy & Mining, Garment Shops, Construction works , Machinery Repair Shops, Building Material Shops, Food & Beverage Factory, Hotels
Product name :
Surface Grinder Grinding Machine
Precision :
High Precision
Application :
Metal Processing
Table size :
630x1250mm
Grinding area :
600x1250mm
Electro magnetic chuck size (pcs.) :
600x1000x1mm
Max. loading capacity (include chuck) :
970kg
After-sales Service Provided :
Provided
Machine Type :
Suface Grinding Machine
Color :
Cutomized
Price :
$26,900.00/sets 1-2 sets
MOQ :
1 set
Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Product Description
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell

STANDARD ACCESSORIES:

PLC+SMART auto. grinding controller,
Coolant tank,
Work lamp,
Balancing arbor,
Wheel flange and extractor,
Wheel dresser stand,
Y/Z axis electrical wheel(MPG),
Splashing guard,
Standard grinding wheel,
Leveling wedge and bolts,
Tools & tool-box,
Operation manual (English edition).

OPTIONAL ACCESSORIES:

Balancing stand,
Magnetic separator,
Paper filter,
Oil tank guard,
Electrical magnetic chuck,
Built-in magnetic chuck controller,
Parallel wheel dresser,
2 axis digital readout,
Extra wheel flange.
Specification
SPECIFICATION
UNIT
SG-60125FR
Table size
mm
630x1250
Grinding area
mm
600x1250
Distance from spindle to table
mm
600
Electro magnetic chuck size (pcs.)
mm
600x1000x1
Max. loading capacity (include chuck)
kg
970
Table longitudinal feed speed
m/min
5-25
Cross intermittent feed rate
mm/str
0-30
Cross continuous feed speed
mm/min
0-1500
Cross feed rate (MPG)
mm/gra
0.005
Vertical intermittent feed rate
mm/str
0.005-0.05
Vertical continuous feed speed
mm/min
0-600
Vertical feed rate (MPG)
mm/gra
0.005
Grinding wheel size
mm
350x40x127
Main motor power
kw
7.5
Package dimensions (LxWxH)
mm
4340x2300x2500
Machine weight
kg
6500
Client feedback
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Factory Display：
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
Electro Magnetic Chuck Size pcs. 600x1000x1mm Flat Grinding Machine / Directly Sell
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
