Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Specifications
CNC or Not :
Normal
Condition :
New
Grinding Length(mm) :
450
Surface Roughness(μm) :
0.32 μm
Table Size(mm) :
254x508
Table Travel (X) (mm) :
275
Table Travel (Y) (mm) :
560
Year :
2024
Place of Origin :
Henan, China
Brand Name :
TIMEWAY
Dimension(L*W*H) :
2300x1600x1680mm
Weight (KG) :
1800
Power (kW) :
2.2
Warranty :
1 Year
Key Selling Points :
Competitive Price
Showroom Location :
India, Indonesia, Germany, Japan, Australia, Egypt, South Africa, South Korea, Russia, Colombia, Italy, Chile, Algeria, United States
Marketing Type :
New Product 2024
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Motor, Pump, PLC
Applicable Industries :
Manufacturing Plant, Energy & Mining, Construction works , Machinery Repair Shops, Building Material Shops
Type :
Surface Grinding Machine
Product name :
Saddle Moving Type Surface Grinder
Table size :
254x508mm
Electro magnetic chuck size :
250x500mm
Distance from spindle to table :
450mm
Table cross travel :
275mm
Table longitudinal travel :
560mm
Grinding wheel size :
200x20x31.75mm
Main motor power :
2.2kw
Machine weight :
1800kg
Price :
$19,000.00/sets 1-2 sets
MOQ :
1 set
Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Product Description

Saddle Moving Type Surface Grinder:

SG-AH: auto feed on cross, hydraulic transmission on longitudinal, manual on vertical.
SG-AHR: auto feed on cross, hydraulic transmission on longitudinal, rapid movement on vertical.
SG-AHD: auto feed on cross, hydraulic transmission on longitudinal, auto feed on vertical.
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024

STANDARD ACCESSORIES:

Working lamp,
Balancing arbor,
Standard grinding wheel,
Magnetic chuck,
Built-in magnetic chuck controller,
Coolant tank,
Wheel flange and extractor,
Wheel dresser stand,
Lubrication system,
Tool box & tools,
Leveling wedge and screw,
Operation manual (English edition).

OPTIONAL ACCESSORIES:

Diamond pen,
Balancing stand,
2 axis digital readout,
Extra wheel flange,
Rear splashing guard,
Closed safe guard,
Oil tank guard,
Dust exhaust,
Parallel wheel dresser,
Radius dresser,
Angle dresser,
Side dresser,
Sinusoidal magnetic table,
Electronic handwheel,
Magnetic separator,
Paper filter.
Specification
SPECIFICATION
UNIT
SG-2550AH
SG-2550AHR
SG-2550AHD
Table size
mm
254x508
Electro magnetic chuck size
mm
250x500
Distance from spindle to table
mm
450
Table cross travel
mm
275
Table longitudinal travel
mm
560
Loading capacity (include chuck)
kg
180
Longitudinal feed speed
m/min
5-25
Table cross intermittent feed rate
mm/str
0.1-8
Table cross rapid feed speed
mm/min
990
Table cross feed of handwheel
mm/gra
0.02
Wheelhead vertical intermittent feed rate
mm/str
AH: -;
AHR: -;
AHD: 0.005-0.5;
Wheelhead vertical rapid feed speed
mm/min
AH: -;
AHR: 650;
AHD: 480;
Wheelhead vertical feed of handwheel
mm/gra
0.005
Spindle speed (50/60HZ)
rpm
2850/3450
Grinding wheel size
mm
200x20x31.75
Main motor power
kw
2.2
Machine dimensions (LxWxH)
cm
230x160x168
Package dimensions (LxWxH)
cm
200x210x215
Machine weight
kg
1800
Client feedback
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Factory Display：
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
Saddle Surface Grinder Machine SG-2550AH/AHR/AHD with 0.32 μm Surface Roughness in 2024
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
