PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
Specifications
Condition :
New
Grinding Length(mm) :
2000
Surface Roughness(μm) :
0.02 μm
Table Travel (X) (mm) :
1600
Table Travel (Y) (mm) :
2000
Place of Origin :
Henan, China
Brand Name :
TIMAC
Weight (KG) :
18000
Warranty :
1 Year
Key Selling Points :
Automatic
Showroom Location :
Indonesia, France, Canada, Russia
Marketing Type :
Ordinary Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Motor, Bearing, Gearbox
Applicable Industries :
Manufacturing Plant
Table width :
1600mm
Table length :
2/3/4/6/8m
Gantry width :
2200mm
Max. grinding width :
2000mm
Max. grinding length :
2000-8000mm
Max. grinding height :
600/800/1000mm
Vertical wheelhead motor power :
11/15kw
Vertical grinding wheel size :
400x40x127mm
Horizontal wheelhead motor power :
22kw
Horizontal grinding wheel size :
500x100x203mm
Packaging Details :
Wooden cases(can be fumigated)
Port :
China Port
Supply Ability :
150 Set/Sets per Month
Price :
$155,000.00/sets 1-2 sets
MOQ :
1 set
Description
Product Description
Guideway Grinderd DSG-1600/1600A
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000

Features:

* The gantry surface grinder standard with a horizontal wheelhead, according to requirement, optional a vertical wheelhead.single saddle and double saddles, Double saddle can realize vertical grinding head and horizontal grinding head without interference grinding.
* This series of machine is a PLC gantry surface grinder with advanced technology of machine, electricity and liquid, which mainly serves the mechanical industry and mould industry, and is suitable for precise grinding of steel parts, cast iron and non-ferrous metals.
* The machine adopts the gantry type layout, which is composed of double column, beam and bed frame.
* Beam with 60° obliquebeam structure, mechanical performance is good, strong rigidity.
* The main spindle of grinding head adopts hydraulic-dynamic and static bush structure. It has the advantages of high motion accuracy, no wear, long life, small starting power, alrge bearing capacity and good vibration resistance.
* The working table is driven by oil cylinder, and can be stepless speed regulation, with mooth movement and low noise.
* Machine running reliable, cost-effective. Compact structure, small floor space and easy operation; high raliability as a working machine.
* High rigidity box casting structure and thermal symmetrical deformation structure.
* High rigidity, high precision hydro-dynamic and hydro-static spindle.
* Large feed amount, high efficency.
* Hydraulic system temperature rise is small, low energy consumption.
* Rotating of vertical grinding head positioning with end gear plate 360° rotating table.
Specification
Specification
Unit
DSG-1250A
DSG-1600A
DSG-2000A
Table width
mm
1250
1600
2000
Table length
m
2/3/4/6/8
2/3/4/6/8
2/3/4/6/8
Gantry width
mm
1700
2200
2600
Max. grinding width
mm
1500
2000
2400
Max. grinding length
mm
2000-8000
2000-8000
2000-8000
Max. grinding height
mm
600/800/1000
600/800/1000
600/800/1000
Horizontal wheelhead intermittent feed rate
mm/str
3-30
3-30
3-30
Horizontal wheelhead feed of MPG
mm
0.005
0.005
0.005
Horizontal wheelhead motor power
kw
22
22
22
Horizontal grinding wheel size
mm
500x100x203
500x100x203
500x100x203
Horizontal spindle speed
rpm
1050
1050
1050
Vertical wheelhead swivel angle
°
±110°
±110°
±110°
Vertical wheelhead feed of MPG
mm
0.005
0.005
0.005
Vertical wheelhead motor power
kw
11/15
11/15
11/15
Vertical grinding wheel size
mm
400x40x127
400x40x127
400x40x127
Vertical spindle speed
rpm
1440
1440
1440
Packing & Delivery
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
This is the picture of the packaging in our factory！You can see our package is standardized and centralized , then they will be shipped to your designated place.
Positive Comments From Customers
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
This picture is the customer's favorable feedback to us. A picture can't mean anything, but we insist on the quality of the machine, we believe that repeat customers will be more and more.
Company Introduction
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
Since our company established, we have obtained many certificates. The above picture is for your reference. We will continue to provide excellent machine tools for domestic and foreign users.
Factory Display：
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
Text Introduction：
PLC Gantry Surface Grinder Machine for Accurate Surface Finishing Weight KG 18000
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
