High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
Specifications
Type :
Universal
Range of Spindle Speed(r.p.m) :
65 - 4500
Number of Axes :
3
No. of Spindles :
Single
Machining Capacity :
Medium Duty
Spindle Taper :
R8 (Optional: ISO40)
Table Travel (X) (mm) :
750/850
Table Travel (Y) (mm) :
400
Table Travel (Z) (mm) :
103
Positioning Accuracy (mm) :
±0.005
Repeatability (X/Y/Z) (mm) :
±0.003
Place of Origin :
Henan, China
Brand Name :
Timeway
Model Number :
KTM250
Voltage :
220V/380V
Key Selling Points :
Multifunctional
Weight (KG) :
1400
Warranty :
1 Year
Max. Table Load(kg) :
280 kg
Marketing Type :
Ordinary Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
CNC or Not :
CNC
Product name :
Mini Cnc Milling Machine
Machine Type :
Table Moving
After-sales Service Provided :
Service Machinery Overseas
Name :
Vertical Metal Machine
Keyword :
China Milling Machine
Application :
Metal Machining
Function :
Machining Metal
Precision :
High Precision
Usage :
Processing Machine
Condition :
New
Showroom Location :
Egypt, Canada, Turkey, Italy, France, Viet Nam, Peru, Saudi Arabia, Russia, Spain, South Korea, Chile, Romania, Bangladesh, Nigeria, Uzbekistan
Year :
2023
Applicable Industries :
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Energy & Mining, Advertising Company, Other
Core Components :
Bearing, Motor, Gear, Gearbox, Other
Packaging Details :
Wooden cases(can be fumigated)
Port :
China Port
Supply Ability :
150 Set/Sets per Month
Price :
$6,600.00/sets 1-2 sets
MOQ :
1 set
Description
Products Description
KTM250
Turret Milling Machine:
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
Specification
Unit
KTM250
Table size
mm
254x1270/254x1370
T-slot (No./width)
3/16
Loading capacity
kg
280
Longitudinal travel (X)
mm
750/850
Cross travel (Y)
mm
400
Spindle quill travel (Z)
mm
103
X/Y/Z-axis rapid feed speed
mm/min
5000
X/Y/Z-axis servo motor power
kw
1
Knee vertical travel
mm
400
Ram travel
mm
470
Distance from spindle to table
mm
0-400
Spindle speed
rpm
16steps, 50HZ: 65-4500/60HZ: 80-5440 (Optional: Variable 60-4200 / KTM300: 60-3600)
Spindle taper
-
R8 (Optional: ISO40)
Main motor power
kw
2.2
Mill head swivel angle
°
±90°
Mill head tilting angle
°
±45°
CNC controller
-
FANUC or SIEMENS or GSK
Package size (LxWxH)
cm
190x200x223
Gross weight
kg
1400
Ram swivel angle
°
180°
Net weight
kg
1640/1680
Packing size (LxWxH) One
mm
160x170x220
Packing size (LxWxH) Two
mm
170x220x220
Positive Comments From Customers
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
Company Introduction
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
Factory Display：
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
Text Introduction：
High Precision Table Moving CNC Turret Milling Machine KTM250 Outlet for Metal Machining
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
