UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
Specifications
Place of Origin :
China
Brand Name :
TIMEWAY
Model Number :
UTMK320
Packaging Details :
Wooden cases(can be fumigated)
Supply Ability :
150 Set/Sets per Month
Price :
$18,000.00/sets 1-2 sets
Type :
VERTICAL
Range of Spindle Speed(r.p.m) :
40 - 2000
Number of Axes :
3
No. of Spindles :
Single
Machining Capacity :
Medium Duty
Spindle Taper :
NT40
Table Travel (X) (mm) :
405
Table Travel (Y) (mm) :
305
Table Travel (Z) (mm) :
400
Positioning Accuracy (mm) :
±0.002
Repeatability (X/Y/Z) (mm) :
±0.001
Voltage :
220V/330
Dimension(L*W*H) :
1500x1700x1800
CNC Control System :
Siemens
Key Selling Points :
Multifunctional
Weight (KG) :
1450
Warranty :
1 Year
Max. Table Load(kg) :
160 kg
Marketing Type :
Hot Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Spindle Speed :
40-2000 (2)
Product name :
Cnc Milling Machine
CNC or Not :
CNC Systemn
Machine Type :
CNC Mill Machine
Keyword :
Cnc 3 Axis Milling Machine
Application :
Metal Machining
Usage :
Processing Machine
Function :
Vertical Milling Machining
CNC Controller :
Fanuc Siemens Syntec KND GSK
Precision :
High Precision
Condition :
New
Applicable Industries :
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Restaurant
Showroom Location :
Egypt, United Kingdom, Italy, France, Germany, Viet Nam, Philippines, Peru, Indonesia, Pakistan, Russia, Thailand, South Korea, Chile, Romania
Core Components :
Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Other, Gearbox
Table Travel (mm) :
750x320
Year :
2023
Port :
China Port
MOQ :
1 set
Description
Products Description
UTMK320
Tool Milling Machine(CNC):
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
Specification
Unit
UTM320
UTM400
UTM450
Work space dimensions
mm
750x320
800x400
850x450
Vertical table dimensions
mm
890x225
1020x225
1190x250
T-slots,work table
mm
(5)14x63
(6)14x63
(7)14x63
T-slots,vertical table
mm
(3)14x63
(3)14x63
(3)14x63
Table load capacity
kg
160
200
300
Travel
Longitudinal(X)
mm
405
500
600
Travel
Transverse(Y)
mm
305
400
450
Travel
Vertical(Z)
mm
400
400
450
Speed range
rpm
(2)40-2000
(2)40-2000
(2)40-2000
Spindle mount
NT40
NT40
NT40
Feeds X Y Z axis
mm/min
10-1000
10-1000
10-1000
Rapid feed
mm/min
1200
1200
1200
Quill stroke
mm
60
60
60
Main motor rating
kw
3.7
3.7
5.5
Feed motor rating
N.M
X:7.7
X:7.7
X:10
Y:7.7
Y:7.7
Y:10
Z:10
Z:10
Z:15
Dimensions (LxWxH)
mm
1500x1700x1800
1500x1700x1800
1600x1800x2000
Weight
Kg
1450
1550
1750
Positive Comments From Customers
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
Shipping
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
Exhibitions
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm

TIMEWAY at EMO Hannover

TIMEWAY machine participates in the EMO Hannover exhibition every time, which is Europe's leading machine tool and metal processing technology exhibition. At the exhibition, TIMEWAY machine demonstrated its advanced machine tools and processing technology, as well as comprehensive solutions for different industries and application fields. These solutions include precision machining and production of high-quality metal parts for the automotive, aerospace, energy, and other sectors.
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm

TIMEWAY at CIMT

CIMT is held in China, the hometown of TIMEWAY machine, so TIMEWAY machine will participate in the CIMT exhibition every time. This is the China International Machine Tool Exhibition and one of the largest machine tool exhibitions in Asia. At the exhibition, TIMEWAY displayed its diversified machine tool products, including CNC machine tools, machining centers, gear processing machine tools, precision measuring equipment, etc.
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm

TIMEWAY at Metalloobrabotka

TIMEWAY machine participated in the Metalloobrabotka exhibition held in Moscow, which is a professional exhibition for the metal processing and machine tool industry in Russia and surrounding areas. At the exhibition, TIMEWAY machine booth attracted the attention of many exhibitors and industry experts. The company's professional team had in-depth exchanges with exhibitors and visitors from Russia and other countries and regions, sharing valuable experience and the latest industry trends. In addition, TIMEWAY machine has also participated in exhibitions in many countries and regions.
Company Introduction
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
Factory Display:
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
Text Introduction:
UTMK320 CNC Tool Milling Machine Professional Precise Table Travel 750x320mm
Company Profile:
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
