QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
Specifications
Type :
TURNING CENTER
Max. Length of Workpiece (mm) :
1000
Machining Capacity :
Medium Duty
Width of bed (mm) :
600 mm
Spindle Motor Power(kW) :
15
No. of Spindles :
Single
Number of Axes :
2
Travel (X Axis)(mm) :
420 mm
Travel (Z Axis)(mm) :
850 mm
Place of Origin :
Henan, China
CNC Control System :
FANUC
Tool Post Stations :
4
Weight (KG) :
6000
Warranty :
1 Year
Key Selling Points :
Automatic
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
CNC or Not :
CNC
Machine Type :
Lathe Machine CNC
Function :
Metal Turning
After-sales Service Provided :
Online Support
Precision :
High Precision Machine
Max. Swing Over Bed :
800mm
Spindle speed :
20-420rpm
Loading capacity :
4000kg
Distance between centers :
1000mm
Pipe threading range :
120-250mm
Condition :
New
Showroom Location :
Canada, United Kingdom, Italy, France, Germany, Russia, Spain, South Africa
Max. Spindle Speed (r.p.m) :
420 r.p.m
Spindle Bore(mm) :
255
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction works , Energy & Mining, Other
Marketing Type :
Hot Product
Core Components :
Other
Price :
$26,000.00/sets 1-2 sets
MOQ :
1 set
Description
Product Description
QK-255F Series CNC Oil Country Lathe Pipe Thread Machining Center with 420mm X Axis Travel
Specification
Specification
QK-255F
Max. swing over bed
800mm
Max. swing over cross slide
480mm
Distance between centers
1000mm
Pipe threading range
120-250mm
Bed width
600mm
Loading capacity
4000kg
Spindle bore
255mm
Spindle speed steps (manual)
4 steps (inverter)
Spindle speed
20-420rpm
Chuck size
630mm
Chuck type (manual)
4-jaw
Turret type (electric)
V4
Tool shank size
32x32mm
X-axis travel
420mm
Z-axis travel
850mm
X-axis rapid feed speed
4000mm/min
Z-axis rapid feed speed
6000mm/min
Tailstock quill diameter
120mm
Tailstock quill taper
MT6
Main motor power
15kw
Machine dimensions (LxWxH)
3600x1930x1900mm
Machine weight
6000kg

STANDARD ACCESSORIES:

FANUC/GSK/SIEMENS CNC system,
Big bore chuck (Front & Rear),
4-station electric tool-post,
Work lamp,
Pilot lamp,
Cooling system,
Semi-closed guard, etc.

OPTIONAL ACCESSORIES:

Penumatic chuck,
Other tool-post,
Chip conveyor,
Air conditioner,
Rear support for long pipe.
