Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Specifications
Type :
Horizontal
Max. Length of Workpiece (mm) :
15003000 mm
Structure :
Flat Bed Lathe
Machining Capacity :
Light Duty
Width of bed (mm) :
755 mm
Spindle Motor Power(kW) :
22
No. of Spindles :
Single
Number of Axes :
2
Travel (X Axis)(mm) :
520 mm
Travel (Z Axis)(mm) :
300 mm
Place of Origin :
Henan, China
Dimension(L*W*H) :
6500*2220*2120
Brand Name :
Timeway
Model Number :
QK-440
CNC Control System :
FANUC/SIEMENS/GSK
Tool Post Stations :
4
Weight (KG) :
13000
Warranty :
1 Year
Key Selling Points :
High-accuracy
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Product type :
Cnc Horizontal Turning Lathe Machine
CNC or Not :
CNC
Machine Type :
CNC Pipe Threading Lathe
Name :
High Precision CNC Lathe Machine
Keyword :
Cnc Lateh Machine
Color :
Customer Optional
Max. length of workpiece :
15003000
Control system :
SIEMENS GSK FANUC (optional)
Processing :
High Accuracy High Speed
Function :
Cnc Pipe Thread
Condition :
New
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant, Retail
Showroom Location :
Egypt, Brazil, Russia
Marketing Type :
Hot Product 2019
Core Components :
Bearing, Motor
Year :
Least day
Max. Spindle Speed (r.p.m) :
205 r.p.m
Spindle Bore(mm) :
440mm
Max. Turned Length (mm) :
2750
Packaging Details :
Wooden cases(can be fumigated)
Port :
China Port
Supply Ability :
150 Set/Sets per Month
Price :
$63,000.00/sets 1-2 sets
MOQ :
1 set
Description
Product Description
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Applications of the CNC oil country lathe:
The CNC oil country lathe meets the special requirements of users in the petroleum, geological, mining and chemical industries, and in agricultural irrigation and drainage, it is able to cut various straight and taper pipe threads of union joints, drill rods, casting pipes, drain pipes, well castings and water pump pipes more economically and efficiently as compared with the engine lathe, however, it may serve as an engine lathe to cut various metric, withworth and module threads, shafts and disks.

››››› The lathe is equipped with a taper turning attachment which can work out long taper.
››››› The lathe is equipped with double chucks which can powerful clamp long parts.
››››› The lathe is equipped with rear support which can auxiliary support longer parts.
Specification
Specifications
Unit
QK-440
Swing over bed
mm
1000
Swing over cross slide
mm
610
Distance between centers
mm
1500/3000
Pipe threading range
mm
270-430
Bed width
mm
755
Max. load capacity
kg
6000
Spindle bore
mm
440
Spindle speed steps
steps
stepless (3shifts)
Spindle speed
rpm
8-205
Chuck size
mm
1000
Chuck type (electric)
-
4-jaw
Turret type (electric)
-
V4
Tool shank size
mm
40x40
X-axis travel
mm
520
Z-axis travel
mm
1250
X-axis rapid feed speed
mm/min
4000
Z-axis rapid feed speed
mm/min
4000
Tailstock quill diameter
mm
140
Tailstock quill taper
-
MT6
Tailstock quill travel
mm
300
Main motor power
kw
22
Coolant motor power
kw
0.125
Machine dimensions
mm
5000/6500x2200x2200
Machine weight
kg
13000/14000
Packing & Delivery
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Company Profile
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.

Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
