CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
Specifications
Type :
Horizontal
Max. Length of Workpiece (mm) :
1000
Structure :
Flat Bed Lathe
Machining Capacity :
Light Duty
Max. Weight of Workpiece(kg) :
5000
No. of Spindles :
Single
Number of Axes :
2
Travel (X Axis)(mm) :
390 mm
Travel (Z Axis)(mm) :
450 mm
Positioning Accuracy (mm) :
±0.001
Repeatability (X/Y/Z) (mm) :
±0.002
Place of Origin :
China
Dimension(L*W*H) :
3227 1800 1850
Model Number :
QK-130
CNC Control System :
KND
Tool Post Stations :
4
Weight (KG) :
6600
Warranty :
1 Year
Key Selling Points :
Multifunctional, High Rigidity
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Range of Spindle Speed(r.p.m) :
20 - 1000 r.p.m
Travel (Y Axis)(mm) :
260 mm
Spindle Taper :
Metric 140
Cutting torque :
66 N.m
Rapid Feed Speed(mm/min) :
3 - 6 mm/min
Feed Speed(mm/min) :
2 - 9 mm/min
Min. Time of Tool Change(s) :
6
CNC or Not :
CNC Lathe Machine
Precision :
High Precision Machine
Control system :
SIEMENS GSK FANUC
Spindle speed :
20-1000rpm (manual 3steps)
After Warranty Service :
1 Year/12 Months
Max. Swing Over Bed :
800mm
CNC Controller :
Fanuc Simens GSK
Distance between centers :
1000/1500/2000/3000mm
Chuck size :
380mm (3-jaw)
Section of tool shank :
40 40mm
Price :
$20,666.00/sets 1-2 sets
MOQ :
1 set
Description
Product Description
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
Specification
Specification
QK-130
Pipe threading range
30-120mm
Max. swing over bed
800mm
Max. swing over cross slide
450mm
Max. length of workpiece
1000/1500/2000/3000mm
Max. turning length
800/1350/1800/2800mm
Bed width
550mm
Spindle nose
C15
Spindle taper
Metric 140
Spindle bore
130mm
Spindle center taper
MT6
Spindle speed
20-1000rpm (manual 3steps)
Chuck size
Φ380mm (3-jaw)
Min. feed increment of X/Z-axis
0.001/0.001mm
X/Z-axis rapid feed speed
3/6m/min
X-axis travel
390mm
Turret type
V4, □240
Section of tool shank
40x40mm
Indexing repeatility
0.008mm
Max. cutting force
19600N
Tailstock quill diameter
100mm
Tailstock quill travel
250mm
Tailstock quill taper
MT5
Main motor power
11kw
Working accuracy
IT6-IT7um
Surface roughness
Ra1.6um
Machine length
3227/3677/4177/5177mnm
Machine width
1800mm
Machine height
1850mm

STANDARD ACCESSORIES:

FANUC/GSK/SIEMENS CNC system,
Big bore chuck (Front & Rear),
4-station electric tool-post,
Work lamp,
Pilot lamp,
Semi-closed guard,
Manual pulse generator (MPG), Dead centers, Oil gun, Automatic lubrication pump,
Manual moving tailstock,
Tools & tool-box,
Leveling wedge & bolts,
Operation manual (English).

OPTIONAL ACCESSORIES:

Penumatic chuck,
Other tool-post,
Chip conveyor,
Air conditioner,
Rear support for long pipe.
One-Stop Shopping
You can click on the picture to view the products you are interested in
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
Factory Display：
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
CNC Pipe Threading Lathe Torno QK-130 CNC Machine Max. Length of Workpiece mm 1000
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
