Specifications
Max. Length of Workpiece (mm) :
3000
Range of Spindle Speed(r.p.m) :
30 - 650 r.p.m
Machining Capacity :
Medium Duty
Type :
Horizontal
Spindle Motor Power(kW) :
11
Place of Origin :
Henan, China
Brand Name :
Timeway
Model Number :
Q-130
Dimension(L*W*H) :
3700/5200x1500x1500mm
Weight (KG) :
4000 KG
Warranty :
1 Year
Key Selling Points :
Competitive Price
Marketing Type :
New Product 2024
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Name :
Manual Lathe Machine
Machine Type :
Horizontal Normal Lathe
Product Name :
Manual Metal Lathe Machine
Precision :
High Precision
Distance between centers :
1500mm/3000mm
Max. swing over bed :
630/800mm
Spindle speed :
30-650rpm
Spindle bore :
130mm
Max. swing over cross slide :
340/520mm
Machine weight :
4000/5200kg
Condition :
New
Spindle Bore(mm) :
130
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Construction works , Energy & Mining
Showroom Location :
Canada, United States, Italy, France, Germany, Viet Nam, Peru, India, Russia, Spain, Thailand, Japan, Malaysia, Australia
Core Components :
Motor, Engine
Max. Turned Length (mm) :
3000 mm
Year :
2024
Price :
$30,988.00/sets 1-2 sets
MOQ :
1 set
Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Product Description
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Specification

STANDARD ACCESSORIES:

√ Big bore chuck (Front & Rear)
√ Dead centers
√ 4-station electric tool-post
√Taper turning attachment
√ Cooling system
√ Work lamp
√ Chip collecting plate
√ General tools
√ Leveling wedge & bolts
√ Operation manual (English)

OPTIONAL ACCESSORIES:

_ 2 or 3-axis DRO
_ Chuck guard
_ Tool-post guard
_ Rear splash guard
_ Rear support for long pipe
SPECIFICATION
UNIT
Q-130
Max. swing over bed
mm
630/800
Max. swing over cross slide
mm
340/520
Distance between centers
mm
1500/3000
Pipe threading range
mm
30-126
Bed width
mm
550
X-axis travel
mm
320/420
Z-axis travel
mm
1350/2850
Loading capacity
kg
3000
Spindle bore
mm
130
Spindle speed step
steps
CCW:18/CW:9
Spindle speed
rpm
30-650
Chuck size
mm
400
Chuck type(manual)
-
4-jaw
Turret type(manual)
-
V4
Tool shank size
mm
30x30
X-axis feed range(steps)
mm/r
0.02-0.45(22)
X-axis rapid feed speed
mm/min
2300
Z-axis feed range(steps)
mm/r
0.07-1.33(26)
Z-axis rapid feed speed
mm/min
4000
No. of Metric thread and range
mm
1-24(52)
No. of Inch thread and range
TPI
2-28(40)
Tailstock quill diameter
mm
100
Tailstock quill taper
-
MT5
Tailstock quill travel
mm
250
Main motor power
kw
11
Rapid feed motor power
kw
0.3
Coolant motor power
kw
0.125
Machine dimensions(LxWxH)
mm
3700/5200x1500x1500
Machine weight
kg
4000/5200
Client feedback
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Factory Display：
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
Timeway High Precision Q-130 Pipe Threading Turning Lathe for Metal in Energy Mining
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
