TCSUNBOW DDR5 Memory SODIMM Series
TCSUNBOW DDR5 Memory SODIMM Series
TCSUNBOW DDR5 Memory SODIMM Series
TCSUNBOW DDR5 Memory SODIMM Series
TCSUNBOW DDR5 Memory SODIMM Series
TCSUNBOW DDR5 Memory SODIMM Series
TCSUNBOW DDR5 Memory SODIMM Series
TCSUNBOW DDR5 Memory SODIMM Series
Specifications
Model Number :
DDR5 SODIMM Series
Operating Temperature Range :
0-75℃
MOQ :
1
Storage Temperature Range :
-40-75℃
Delivery Time :
1-7
Payment Terms :
L/C,D/P,T/T
Certification :
RoHS,CE,FCC,ISO
Form Factor :
SODIMM
Brand Name :
TCSUNBOW/TCS
Memory Type :
DDR5 DRAM
Place of Origin :
China
Installation Type :
Internal
Description
  • Built on the DDR5 standard, offering higher potential bandwidth and improved power efficiency compared to DDR4 modules of similar capacity.
  • With frequency options from 4800MHz to 6400MHz, the series provides flexible performance levels for different system requirements.
  • Additional system memory provides more room for running multiple applications, handling larger files, and managing everyday workloads.
  • Designed for systems supporting DDR5 memory, the series provides a current-generation memory solution for laptops and compact PCs.
  • The combination of different capacities and frequencies allows system builders and users to select a configuration that fits their performance requirements.
Series DDR5 SODIMM Series
Brand TCSUNBOW
Capacity 8GB 16GB 32GB
Model Number DDR5-NB-8GB DDR5-NB-16GB DDR5-NB-32GB
EAN 6935515104186 6935515104193 6935515140474 6935515140481 6935515104209 6935515104216 6935515104223 6935515104230 6935515104247 6935515104254 6935515104261 6935515104278
Memory Speed / Frequency 4800MHz 5600MHz 6000MHZ 6400MHZ 4800MHz 5600MHz 6000MHZ 6400MHZ 4800MHz 5600MHz 6000MHz 6400MHz
Rank (1Rx8/2Rx8/8Rx4) 1Rx8 1Rx8 2Rx8 2Rx8 1Rx8 1Rx8 2Rx8 2Rx8 2Rx8 2Rx8 2Rx8 2Rx8
CAS Latency CL40-40-40-77 CL46-45-45-90 CL46-48-48-96 CL32-39-39-80 CL40-40-40-77 CL46-45-45-90 CL46-48-48-96 CL32-39-39-80 CL40-40-40-77 CL46-45-45-90 CL46-48-48-96 CL32-39-39-80
Operating Voltage 1.1V 1.1V 1.35V 1.4V 1.1V 1.1V 1.35V 1.4V 1.1V 1.1V 1.35V 1.1V
No. of Memory IC 8/16
Power Consumption 3W
Controller IC NO
Overclock Support (YES / NO) NO
ECC (Error Correction Code) (YES/NO) NO
Net Weight (g) 10g
Gross Weight (g) 28g
Pin Count 260
OEM/ODM Support YES
Heat Sink / Heat Spreader NO
Form Factor SODIMM
Computer Memory Type (DRAM/SDRAM) DRAM
Operating Temperature 0-70℃
Storage Temperature -40~85℃
Warranty 3 Years
No. of Memory Channels (Single/Dual) (Single/Dual)
Product Dimension (W x D x H) in mm 70x30x3.5mm
Buffered / Un-buffered Memory Un-buffered Memory
Memory IC Brand Micron/Samsung/Sk Hynix
Note: All specifications and performance data are for reference purposes only. Actual results may vary depending on platform and system configuration. TCSUNBOW/TCS reserves the right of final interpretation.
