High-Pressure Spray Washer: Efficient Degreasing & Wax Removal for Auto Parts, Precision Cleaning & Drying.

Spray cleaning machine

High-Pressure Spray Washer Overview:

Introduction of process flow:(workpiece flow direction → left in and right out)

Manual feeding → ultrasonic cleaning → fixed-point spraying → air cutting → fixed-point spraying → mobile spraying → mobile air cutting → fixed-point air cutting → vacuum drying → cooling section → automatic unloading (truss manipulator) → full inspection and packaging

Basic parameters of High-Pressure Spray Washer:

Height of conveying: 1000±50mm (consistent with the height of the whole inspection line)

Effective width of chain conveyor: about 900mm (provisional)

Equipment transmission mode: motor + chain, step conveyor

Direction of flow: from left to right

Equipment size: approximately 12000 (length) X 3000 (width) X3100 (height) (mm) (subject to the final production drawing)

Power supply from the customer: 380V±5% / 50HZ / three-phase five-wire system

Total power of the machine: about 150KW average power consumption: about 75KW

Compressed air consumption: pressure greater than or equal to 5㎏f/cm2, flow rate greater than or equal to 200M3/H

For a complete technical solution Of High-Pressure Spray Washer, please contact me. We will customize the design based on your product technical requirements and factory layout.

Our typical customers:

About Us:

Dongguan Hongshun Automation Equipment Co., Ltd. is located in Dongguan City, the global manufacturing capital. It is a professional manufacturer of high-precision surface treatment equipment. Its main products include: We offer a full range of ultrasonic cleaning equipment, vacuum hydrocarbon cleaning machines, high-pressure spray cleaning machines, spraying lines, passivation acid washing equipment, anodizing equipment, electroplating equipment, industrial pure water machines, reclaimed water reuse equipment, tunnel drying furnaces and their peripheral supporting equipment and consumables, etc. We provide turnkey surface treatment projects for our customers. The company integrates independent research and development, production and manufacturing, installation and training, and after-sales service. It also has a complete quality management system and strong technical strength.
