Metal Pipe Spray Cleaning Machine Ultrasonic Cleaning Line With Conveyor Drying Construction Industry
Metal Pipe Spray Cleaning Machine Ultrasonic Cleaning Line With Conveyor Drying Construction Industry
Specifications
Brand Name :
Hongshun
Model Number :
HS-2400SC
Certification :
CCC/CE
Place of Origin :
Guangdong
MOQ :
1 set
Price :
$100,00 to $30,000
Payment Terms :
L/C,T/T
Supply Ability :
5 sets/month
Delivery Time :
50 days
Packaging Details :
film
Applications :
Metal Pipe
conveyor speed :
2-8m/min
spray pressur :
180bar
Power supply :
380±10%/50HZ
Dryer temperature :
80℃
Ultrasonic frequency :
28KHZ
Description

Metal Pipe Spray Cleaning Machine with Variable Speed Conveyor Drying Construction Industry

Spray Cleaning Machine Overview:

Variable speed conveyor (2-8m/min) adapts to different pipe lengths, cleaning via 180bar spray. The 80℃ dryer prevents rust, ideal for construction metal pipes, removing cutting oil and dirt, ensuring welding quality, handling pipes of Φ20-200mm.

Cleaning requirements Reference(residues):

1. Total weight less than or equal to 4.5mg

2. Metal diameter less than or equal to 600um

3. Non-metallic diameter less than or equal to 1800um

4. Fiber length is less than or equal to 4000um

5. After cleaning, there should be no watermark on the surface (with pure water machine), and it should be completely dry (blind hole)

Reference of process flow:(workpiece flow direction → left in and right out)

Manual feeding → ultrasonic cleaning → fixed-point spraying → air cutting → fixed-point spraying → mobile spraying → mobile air cutting → fixed-point air cutting → vacuum drying → cooling section → automatic unloading (truss manipulator) → full inspection and packaging

Partial configuration Of Spray Cleaning Machine:

Hot air drying

quantity

1section (section 8)

Hot air main chamber

Cavity material

➢ δ≈ 1.5mmSUS304 with 50MM insulation layer

Process length

➢ 1 station;

dry beside or over a fire

Main Knot

construct

➢ Automatic doors are set at the front and rear ends of the chamber.

➢ The bottom of the trough is a sloping funnel structure, so that the residual liquid is directly discharged to the drain pipe.

➢ Use clean compressed air.

➢ Fast disassembly and maintenance door cover is provided to facilitate equipment cleaning, maintenance and repair.

fixed point

➢ Multi-nozzle high pressure air cut.

➢ The product starts to heat up.

temperature control

heat

➢ Heating power: wind cut 6KW

thermostat

➢ Omron imported high-quality brand digital temperature controller; mechanical temperature control is also attached.

➢ Temperature control range RT-100℃.

For a complete technical solution Of Spray Cleaning Machine, please contact me. We will customize the design based on your product technical requirements and factory layout.

Our typical customers:

Metal Pipe Spray Cleaning Machine Ultrasonic Cleaning Line With Conveyor Drying Construction Industry Metal Pipe Spray Cleaning Machine Ultrasonic Cleaning Line With Conveyor Drying Construction Industry

About Us:

Dongguan Hongshun Automation Equipment Co., Ltd. is located in Dongguan City, the global manufacturing capital. It is a professional manufacturer of high-precision surface treatment equipment. Its main products include: We offer a full range of ultrasonic cleaning equipment, vacuum hydrocarbon cleaning machines, high-pressure spray cleaning machines, spraying lines, passivation acid washing equipment, anodizing equipment, electroplating equipment, industrial pure water machines, reclaimed water reuse equipment, tunnel drying furnaces and their peripheral supporting equipment and consumables, etc. We provide turnkey surface treatment projects for our customers. The company integrates independent research and development, production and manufacturing, installation and training, and after-sales service. It also has a complete quality management system and strong technical strength.
