6.9 Inch CO₂ PM2.5 VOC Based Ventilation Control Energy Recovery Ventilation ERV Controller
6.9 Inch CO₂ PM2.5 VOC Based Ventilation Control Energy Recovery Ventilation ERV Controller
6.9 Inch CO₂ PM2.5 VOC Based Ventilation Control Energy Recovery Ventilation ERV Controller
6.9 Inch CO₂ PM2.5 VOC Based Ventilation Control Energy Recovery Ventilation ERV Controller
Specifications
Model Number :
G7 MIPI
Supply Ability :
100000pcs
Display :
6.9 Inch Color LCD Touchscreen
Brand Name :
OEM or neutral (no brand)
MOQ :
1
Delivery Time :
2-3 weeks
Price :
US$119
Suitable for fans :
AC/EC/DC fan motors
Product Name :
Smart Fresh Air Ventilation Controller
Payment Terms :
T/T
Built in sensors :
VOC+PM2.5+CO2+Temperature+Humidity
Communication Protocol :
Modbus RTU (Optional)
Mobile App :
Smart Life App / Tuya Smart App
Certification :
CE, RoHS
Place of Origin :
Guangdong, China
Description
Product Overview:

G7 mipi is an intelligent fresh air ventilation controller that integrates multiple sensors such as PM2.5, CO2, temperature, humidity, etc. The device adopts a 6.9-inch HD color screen and a high-sensitivity touch screen design. The device is equipped with WIFI, which can be remotely accessed and controlled through the Internet. At the same time, RS485 port and MODBUS protocol are reserved for communication with smart home, building intelligent control, etc.

  • Energy-Saving Operation
  • Demand-Controlled Ventilation
  • Automatic Energy Optimization
  • Eco Mode
  • Reduced HVAC Energy Consumption


Product Specifications:
* Dimension:
115 × 185 mm

* Display interface:
6.9 inch, 1024 x 600
* Warm-up time:
2 minutes

* Response time:
≤ 10 seconds
* Wiring terminal:
Max 2.5 mm2 wire

* Recovery time:
≤ 30 seconds
* Rated voltage:
AC110-240V, 50/60Hz

* Operating temperature:
-10℃--- +50℃
* Standby Power:
≤ 3.0W

* Operating humidity:
5％RH——90％RH
* Control power:
≤ 200W

* Storage temperature:
-10℃--- +60℃
* Suitable for fans:
AC/EC/DC

* PM2.5 display range:
0ug/m3——999ug/m3
* Temperature display range:
0℃ —— 99℃

* Humidity display range:
0% —— 99%
* Fixing hole distance:
60mm(standard)

* Recognition rate of quiet environment
> 90%


Products Images:


6.9 Inch CO₂ PM2.5 VOC Based Ventilation Control Energy Recovery Ventilation ERV Controller

6.9 Inch CO₂ PM2.5 VOC Based Ventilation Control Energy Recovery Ventilation ERV Controller

6.9 Inch CO₂ PM2.5 VOC Based Ventilation Control Energy Recovery Ventilation ERV Controller

6.9 Inch CO₂ PM2.5 VOC Based Ventilation Control Energy Recovery Ventilation ERV Controller


6.9 Inch CO₂ PM2.5 VOC Based Ventilation Control Energy Recovery Ventilation ERV Controller
