WiFi Smart Fresh Air Dehumidifier Controller With Tuya App RS485 Modbus Integration
WiFi Smart Fresh Air Dehumidifier Controller With Tuya App RS485 Modbus Integration
WiFi Smart Fresh Air Dehumidifier Controller With Tuya App RS485 Modbus Integration
WiFi Smart Fresh Air Dehumidifier Controller With Tuya App RS485 Modbus Integration
Specifications
Model Number :
G6-X-XFCS
MOQ :
1
Delivery Time :
2-3 weeks
Payment Terms :
T/T
Operating humidity :
5％RH----90％RH
Humidity Control :
Intelligent RH (Relative Humidity) Control
Price :
US$105
System Type :
HVAC / Fresh Air / Dehumidifier Integrated System
Rated voltage :
AC110-240V, 50/60Hz
Supply Ability :
100000pcs
Operating temperature :
-10℃--- +50℃
Brand Name :
OEM or neutral (no brand)
Temperature Monitoring :
Supported (Real-time display)
Certification :
CE, RoHS
Place of Origin :
China
Description
Product Overview:

G6-X-XFCS dehumidifier intelligent controller can monitor indoor temperature and humidity, PM2.5, CO2 in real time (optional); It can be connected to WIFI (optional), with ModBus RTU (RS485) interface. Users can connect to the background of smart home and others through ModBus interface to realize monitoring of equipment status.

The controller supports Wi-Fi connectivity and can be remotely monitored and controlled through the Smart Life App or Tuya Smart App, allowing users to manage their ventilation system anytime and anywhere. In addition, the built-in RS485 communication interface enables seamless integration with HVAC systems, building management systems (BMS), and smart building platforms.

It can be widely used in residential, commercial and industrial occasions, and can effectively improve air quality, create a healthy, comfortable, efficient, environmentally friendly and energy-saving living and working environment.

Key Features:
  • Fresh air ventilation + dehumidification integrated control
  • Real-time temperature & humidity monitoring
  • Optional CO₂ / PM2.5 / VOC air quality detection
  • WiFi remote control (Tuya / Smart Life app optional)
  • RS485 Modbus communication for BMS integration
  • Multiple operation modes: Auto / Manual / Drying / RH setting
  • Energy-saving intelligent control system
  • Compatible with HVAC smart building systems
  • OEM/ODM customization available
Specifications:
* Dimension: 86 × 86 × 39 mm
* Warm-up time: 2 minutes
* Fixing hole distance: 60mm (standard)
* Response time: ≤ 10 seconds
* Wiring terminal: Max 2.5 mm2 wire
* Recovery time: ≤ 30 seconds
* Rated voltage: AC110-240V, 50/60Hz
* Operating temperature: -10℃--- +50℃
* Standby Power: ≤ 2.0W
* Operating humidity: 5％RH——90％RH
* Control power: ≤ 200W
* Storage temperature: -10℃--- +60℃
* Suitable for fans: AC/EC/DC
* Storage humidity: ≤ 60％RH
* Temperature display range: 0℃ —— 99℃
* Life: ≥ 3 years
* PM2.5 display range: 1ug/m3——999ug/m3
* CO2 display range: 350ppm——2000ppm
Product Images:

WiFi Smart Fresh Air Dehumidifier Controller With Tuya App RS485 Modbus Integration

WiFi Smart Fresh Air Dehumidifier Controller With Tuya App RS485 Modbus Integration

WiFi Smart Fresh Air Dehumidifier Controller With Tuya App RS485 Modbus Integration

WiFi Smart Fresh Air Dehumidifier Controller With Tuya App RS485 Modbus Integration
