Specifications
Place of Origin :
China
Model Number :
WT-1818-UN
MOQ :
1
Price :
$5.80-6.20
Type :
GNSS Module
Country of Origin :
CHINA
Brand :
OTW
Chipset :
UBLOX
Application :
Positioning, surveying and mapping, etc
Operating mode :
GPS+GLONASS+GALILEO+ BDS
Output Mode :
UART+TTL+R232+USB
Baud rate :
4800bps-921600bps,Default9600bps
NMEA messages :
RMC,VTG,GGA,GSA,GSV,GLL
Update frequency :
1Hz-10Hz(default 1Hz)
Voltage :
3.3V to 5.5V
Power consumption :
20 mA @5V
Size :
18mm*18mm*4mm
Description
Mini hidden bike with built-in GPS receiver Ceramic antenna Cheap signal stability WT-1818-UN
UBLOX GNSS Module 3.3V-5.5V GPS GLONASS GALILEO BDS
Application:
●Drones, law enforcement cameras
●Hd camera, surveying and mapping
●Handheld device
●Smart wear
●Smart agriculture
●Pet tracking
UBLOX GNSS Module 3.3V-5.5V GPS GLONASS GALILEO BDS
Product features:
● Positioning module and antenna integrated ● Can receive 3 GNSS synchronously (GPS/BDS/GLN/GAL) ● Ultra-high sensitivity ● Built-in high-gain LNA and SAW for better performance in weak signal situations, even with passive antennas for fast positioning ● High performance, low power consumption ● Support for all satellite augmentation systems
UBLOX GNSS Module 3.3V-5.5V GPS GLONASS GALILEO BDS

Pin assignment
UBLOX GNSS Module 3.3V-5.5V GPS GLONASS GALILEO BDS

Product Description:
Module performance
Type
WT-1818-UN
Receiver type
GPS/QZSS L1
GLONASS L1
BeiDou B1
Galileo E1
Agreement
NMEA-0183 or custom
Available baud rate
4800bps~921600bps(default9600bps)
Channel
72
Sensitivity
Tracking:-163dBm Hot Start:-148dBm Cold Start -148dBm
Cold start
Average 29 seconds
Hot start
Average 1 seconds
Accuracy
2.5m
Velocity: 0.1 m/s
Timepulse signal: RMS 30 ns
Max Height
18000 m
Max Speed
515 m/s
Max Acceleration
≦ 4G
Regeneration frequency
1Hz -10 Hz
Port
Port
UART/TTL/R232/USB
Physical property
Type
1.25mm 4 pins connector
Size
18mm*18mm*4mm(+/- 0.5mm)
Power supply
Voltage
3.3V~5.5V
Power Consume
20mA@5V
Oerating Environment
Humidity range
5% to 95% non-condensing
Working Temperature
-40℃ to 85℃
Storage Temperature
-40℃ to 105℃
UBLOX GNSS Module 3.3V-5.5V GPS GLONASS GALILEO BDS
Company Profile
Shenzhen Anzewei Technology Co., Ltd. is a scientific and technological company integrating the R & D, production, sales and service of wireless positioning communication products, semi-finished products, finished products and supporting terminals. it has many international well-known enterprises in-depth cooperation resources and a number of elite and senior R & D and design teams.
We always take customer demand as the original strategy, providing wireless and portable high-end consumer electronics solutions, specializing in navigation, positioning, tracking, timing, communications, wireless connections and other professional products, semi-finished products and products, mainly centimeter-level positioning terminals, wearable children's smartwatches, pet track.
UBLOX GNSS Module 3.3V-5.5V GPS GLONASS GALILEO BDS
Logistics & Payment
UBLOX GNSS Module 3.3V-5.5V GPS GLONASS GALILEO BDS
UBLOX GNSS Module 3.3V-5.5V GPS GLONASS GALILEO BDS
UBLOX GNSS Module 3.3V-5.5V GPS GLONASS GALILEO BDS
FAQ
Q1: Are you a manufacturer? Where is your factory? A1: Yes, we are a manufacturer. Our factory is located in Shenzhen, China. Welcome to our factory. Q2: If i place an order how long will it take to delivery it? A2: IT usually takes about only 7-10days on receipt of payment,depends on the quantity ordered and the stock status. Q3: Are the prices on the list final? A3: No, the price is negotiable. It depends on the quantity of your order. Q4: When can I get the price? A4: Usually we quote within 24 hours of receiving an inquiry. If you urgently need to get a price, please call us so that we can let me quote you as soon as possible. Q5: Can I ask for a sample before placing an order? A5: Yes, we are welcome to order samples to test and check the quality. Mixed samples are acceptable. Q6: Can it be customized? A6: Yes. We support custom requirements. Q7: How can you make our business build a long term good relationship? A7: 1. We maintain good quality and competitive price to ensure that our customers benefit; 2. We respect every customer as our friend and sincerely conduct business and make friends with you, wherever you come. If you would like to know more about our company, please contact us immediately.
