Cold Rolled EPS Foam Machine , 35kw Polyurethane Sandwich Panel Machine
Cold Rolled EPS Foam Machine , 35kw Polyurethane Sandwich Panel Machine
Specifications
Brand Name :
LIMING
Model Number :
LM-sandwich12
Certification :
CE、BV、ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, L/C, D/A, D/P
Supply Ability :
450set/Year
Delivery Time :
30 work days
Packaging Details :
Nude、Anti-dust film, Anti-rust cloth
Applicable Industries: :
Building Material Shops, Manufacturing Plant, Construction works
After Warranty Service: :
Video technical support, Online support, Spare parts, Field maintenance and repair service
Power: :
3KW-20.5KW
Chain Size: :
20mm
Warranty :
2 years
Rolling thinckness: :
0.3-0.8mm
Dimension(L*W*H): :
5m*1.3m*1.3m-15m*1.3m*1.4m
Working speed: :
10-14m/min
Voltage: :
According to requst
Description

Polystyrene Cold Rolled Sandwich Panel EPS Foam Sheet Roll Forming Machine

"Polystyrene cold rolled sandwich panel EPS foam sheet roll forming machine" adopts a production process integrating gas, electricity and machinery. It is a mechanical equipment for producing cored color steel sandwich panels.

"Polystyrene cold rolled sandwich panel EPS foam sheet roll forming machine" production line has stable running speed and simple operation.

According to the user's needs, the length of the "Polystyrene cold rolled sandwich panel EPS foam sheet roll forming machine" is controlled by computer positioning, system positioning, and regularly displayed on the touch screen, and automatically counted and corrected.

"Polystyrene cold rolled sandwich panel EPS foam sheet roll forming machine" is driven by a worm gear to ensure a stable and uniform mixing speed.

"Polystyrene cold rolled sandwich panel EPS foam sheet roll forming machine" adopts frequency conversion speed regulation and can automatically cut off according to the preset length of the sandwich panel.

"Polystyrene cold rolled sandwich panel EPS foam sheet roll forming machine" main machine adopts the horizontal composite material of outsourcing rubber roller to protect the color steel plate paint surface and the pressure compound of the sandwich panel.

Technical parameters of Polystyrene Cold Rolled Sandwich Panel EPS Foam Sheet Roll Forming Machine

Item Specification
Raw material Normally 0.2-0.6 aluminum or color steel
Speed 3-6m/min (Depend on the working temperature)
Cutting type Trace flying saw cutting
Drive Chain drive
Electric control system PLC frequency conversion control
Core material EPS board or rock wool
Total power 35kw
Power supply 380V/50HZ Or Customized
Annual Output 600 thousand square meters
Product width 950-1200 mm (Flat Plate)
950-980 mm (Corrugated Composite Board)
Product thickness 40-300mm
Equipment overall dimension (mm) 40000*3600*3300 / 45000*3600*3300
