44 rows Sandwich Panel Production Line , Sandwich Panel Equipment 380v 50Hz
44 rows Sandwich Panel Production Line , Sandwich Panel Equipment 380v 50Hz
Specifications
Brand Name :
LIMING
Model Number :
LM-sandwich8
Certification :
CE、BV、ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, L/C, D/A, D/P
Supply Ability :
450set/Year
Delivery Time :
30 work days
Packaging Details :
Nude、Anti-dust film, Anti-rust cloth
Applicable Industries: :
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction works
Feeding width: :
1220mm, 915mm, 900mm, 1200mm, 1000mm, 1250mm
Production Capacity: :
0-6m/min
Size of sheet: :
1200mm
Warranty :
2 years
Rolling thinckness: :
0.3-0.8mm
Dimension(L*W*H): :
30000*3000*2800mm
Working speed: :
10-14m/min
Voltage: :
380v 50Hz
Description

Rock Wool Sandwich Panel House Modular Sandwich Roll Forming Machine

"Rock wool sandwich panel house modular sandwich roll forming machine " adopts precision low-speed metering pump, frequency conversion speed regulation or stepless speed regulation, and is controlled by a computer, with accurate measurement.

"Rock wool sandwich panel house modular sandwich roll forming machine " can compound flat and corrugated cardboard of various specifications and models. It can produce sandwich composite panels with a thickness of 40mm-300mm and a width of 950mm-1200mm, as well as corrugated high-strength composite panels with a thickness of 40mm-300mm and a width of 950mm-980mm.

"Rock wool sandwich panel house modular sandwich roll forming machine " equipment is suitable for color steel plates, aluminum plates, stainless steel plates, etc. as composite outer materials, and the inner layer is made of rock wool materials.

"Rock wool sandwich panel house modular sandwich roll forming machine " adopts advanced mechatronics production technology, with an annual production capacity of 500,000 square meters.

Technical parameters of Rock Wool Sandwich Panel House Modular Sandwich Roll Forming Machine

No. main parameter of Sandwich panel forming machine line
1 Suitable to process Color steel plate
2 Width of the plate 1000&1200mm
3 Rollers 17-44rows
4 Dimensions 38.0*2.25*2.5m
5 Power 30kw
6 Thickness of the plate 0.3-0.8mm
7 Productivity 2-6m/min
8 Diameter of the roller Φ90mm
9 Weight About 15 T
10 Voltage 380V 50Hz 3phases
11 Material of the cutting plate Cr12
12 Processing precision Within 1.00mm
13 Control system PLC control
