NEW-FLOW ETS3000X Explosion-proof Capillary Temperature Switch | SPDT Microswitch For Hazardous Area
NEW-FLOW ETS3000X Explosion-proof Capillary Temperature Switch | SPDT Microswitch For Hazardous Area
Specifications
Model Number :
NEW-FLOW SME4 SAE4 SME6 SAE6
Displaytype :
LCD, Analog Dial
Brand Name :
NEW-FLOW
Connectiontype :
Threaded, Flanged
MOQ :
1
Delivery Time :
2-4weeks
Outputinterface :
RS485, HART, Modbus
Mountingoptions :
Panel, Wall, Pipe
Responsetime :
≤ 1 ms
Supply Ability :
99pcs/2-4weeks
Operatingtemperature :
-40°C to 85°C
Ingressprotection :
IP65, IP67
Payment Terms :
T/T
Measurementtype :
Gauge, Absolute, Differential
Material :
Stainless Steel, Brass
Price :
380-999USD
Protectionrating :
IP65, IP67
Place of Origin :
China
Mounting :
Panel mount or pipe mount
Productname :
Pressure Measurement Instruments
Packaging Details :
Export standard carton with shockproof inner foam
Mountingtype :
Panel Mount, Wall Mount
Certification :
CO
Calibration :
Factory calibrated
Applications :
Industrial, HVAC, Automotive, Oil & Gas
Description
1. Product Overview

NEW-FLOW ETS3000X explosion-proof temperature switch adopts gas/liquid filled thermal expansion sensing principle, matched with remote stainless steel capillary for long-distance temperature detection.

Die-cast aluminum explosion-proof enclosure meets international hazardous area standards, NEMA4X & IP65 waterproof dustproof. Built-in pure silver SPDT microswitch provides stable on-off signal for temperature alarm, pump/valve interlock, furnace overheat protection. Two contact options (1 contact / 2 contacts) support dual-point temperature control.

2. Core Features
  • Full explosion certification: Class I Groups B/C/D, Class II E/F/G, NEMA 4/7/9, IP65
  • Two sensing types for full temperature coverage

    Liquid-filled: -70℃ ~ +400℃, max capillary 20m

    Gas-filled: -200℃ ~ +650℃, max capillary 30m

  • 1~2 SPDT microswitch, 999.9 pure silver contacts, long service life
  • Electrical rating: 250VAC 5A / 28VDC 5A (resistive), 3A (inductive)
  • Adjustable differential: ±1.6% ~ 3% FS, internal calibration without disassembly
  • Wetted parts SS316 stainless steel, anti-corrosion for chemical media
  • Process connection: 1/2" / 3/4" NPT male; Conduit port: 1/2" NPT female
  • Ambient working temp: -20℃ ~ +70℃, stable under harsh outdoor environment
  • Customizable capillary length, probe insertion depth, dual contacts & special temperature ranges
3. Technical Specification Table
Item Parameter
Model ETS3000X Explosion-proof Temperature Switch
Sensing Type Liquid Filled / Gas Filled
Temp Range Liquid -70℃ ~ +400℃
Temp Range Gas -200℃ ~ +650℃
Max Capillary Length Liquid: 20m; Gas: 30m
Switch Contact 1 or 2 SPDT Microswitch
Contact Material 999.9 Pure Silver
AC Rating 250VAC, Max 5A
DC Rating 28VDC, 5A(resistive) / 3A(inductive)
Switch Differential ±1.6% ~ 3% Full Scale
Explosion Proof Grade Class I B/C/D, Class II E/F/G
Protection Class NEMA4X, IP65
Housing Material Die-cast Aluminum Alloy
Wetted Parts SS316 Stainless Steel
Process Thread 1/2" NPT(M), 3/4" NPT(M)
Wiring Conduit 1/2" NPT(F)
Ambient Temp -20℃ ~ +70℃
Adjustment Mode Internal Adjustment
4. Application Industries
  • Oil & gas refinery, pipeline station
  • Chemical & petrochemical plant
  • Coal mine, dust hazardous workshop
  • Power plant boiler, heat exchanger
  • Pharmaceutical flammable solvent workshop
  • Refrigeration & high-temperature furnace
  • Marine explosion-proof equipment
