WINTERS Semi-Stainless Steel Pressure Gauge with IP65 Protection and 5-Year Warranty - PFQ-40-T-S-A-ZM-(0-4MPa)
WINTERS Semi-Stainless Steel Pressure Gauge with IP65 Protection and 5-Year Warranty - PFQ-40-T-S-A-ZM-(0-4MPa)
WINTERS Semi-Stainless Steel Pressure Gauge with IP65 Protection and 5-Year Warranty - PFQ-40-T-S-A-ZM-(0-4MPa)
WINTERS Semi-Stainless Steel Pressure Gauge with IP65 Protection and 5-Year Warranty - PFQ-40-T-S-A-ZM-(0-4MPa)
Specifications
Brand Name :
WINTERS
Model Number :
PFQ-40-T-S-A-ZM-(0-4MPa)
MOQ :
1
Price :
20USD
Payment Terms :
T/T
Supply Ability :
1PC 6-8WEEK
Delivery Time :
6-8WEEK
Mountingoptions :
Panel mount, Pipe mount, Wall mount
Connectiontype :
Threaded, Flanged
Accuracy :
±0.1% FS
Protectionrating :
IP65, IP67
Displaytype :
Digital LCD, Analog Dial
Material :
Stainless Steel, Brass
Pressurerange :
0 to 10,000 psi
Measurementtype :
Gauge, Absolute, Differential
Application :
Industrial, HVAC, Automotive, Oil & Gas
Outputsignal :
4-20 mA, 0-10 V, Digital
Calibration :
Factory calibrated, Field calibratable
Responsetime :
≤ 1 second
Operatingtemperature :
-40°C to 125°C
Productname :
Pressure Measurement Instruments
Powersupply :
24 V DC
Description
WINTERS Semi-Stainless Steel Pressure Gauge with IP65 Protection and 5-Year Warranty
Model: PFQ-40-T-S-A-ZM-(0-4MPa)
The PFQ-20 Radial 50mm pressure gauge from Winters Instruments combines compact design with reliable performance for space-limited industrial applications. Featuring semi-stainless steel construction with corrosion-resistant properties, this gauge offers excellent value and durability.
Product Specifications
ModelPFQ-20 Radial 50mm
BrandWinters Instruments
Dial Size2" (50mm)
Case Material304 Stainless Steel (Semi-Stainless Steel Construction)
Wetted PartsBrass (316SS Optional)
Window MaterialPolycarbonate (PC)
Bezel304 Stainless Steel Crimped Bezel (Optional U-Clamp for Panel Mounting)
MovementStandard Mechanical Movement (Optional Liquid-Filled for Vibration Resistance)
Accuracy Class±2.5% Full Scale (FS)
ScaleSingle (psi) or Dual Scale (psi/kPa, psi/bar, etc.)
Pressure RangeMultiple Ranges Available (e.g., Vacuum to 15 psi, 30 psi, 60 psi, 100 psi, etc.)
Connection1/4" NPT Male (Standard), with Restrictor Screw; 1/8" or 1/2" NPT Optional
Mounting TypeRadial Mounting (Bottom Connection)
Ambient Temperature-20°C to 70°C
Medium Temperature-40°C to 150°C (Dry); -40°C to 100°C (Liquid-Filled)
Storage Temperature-20°C to 70°C
Over-Pressure LimitSteady Pressure: 75% FS; Fluctuating Pressure: 65% FS; Short-term Pressure: 100% FS (Brass Tube)
IP RatingIP65 (EN 60529)
CertificationCRN Registered; Optional NSF-61-372 (Lead-Free PFQ-LF)
Warranty5-Year Warranty
Key Features
  • Compact 2" (50mm) size ideal for space-limited installations
  • Semi-stainless steel design provides corrosion resistance with cost-effective brass wetted parts
  • IP65 rated for protection against dust and water jets
  • 5-year warranty for long-term reliability
  • CRN registered for compliance with Canadian pressure equipment standards
Optional Features
Available Upgrades: Liquid-Filled (Glycerin/Silicone) for vibration resistance, Lead-Free (PFQ-LF) version for potable water applications, and custom scale markings to meet specific requirements.
