Specifications
Brand Name :
CAF
Model Number :
CAF L329-B804 Highly Corrosive Liquids With Vapor Or Stirring Radar Level Gauges
Certification :
CO
Place of Origin :
China
MOQ :
1
Price :
1200-5000USD
Payment Terms :
T/T
Supply Ability :
99pcs/2-4weeks
Delivery Time :
2-4weeks
Packaging Details :
Standard cardboard box packaging
Responsetime :
Less than 10 ms
Operatingtemperaturerange :
-40°C to 85°C
Outputinterface :
RS485, HART, Modbus
Displaytype :
LCD, Analog Dial
Ingressprotection :
IP65, IP67
Powersupply :
12-24V DC
Material :
Stainless Steel, Brass
Protectionrating :
IP65 to IP67
Measurementrange :
0 to 1000 psi
Calibration :
Factory Calibrated
Power Supply :
24V DC, 110V AC, 220V AC
Operatingtemperature :
-40°C to 125°C
Response Time :
1 ms to 100 ms
Description

1. The L329-B80 series frequency-modulated radar level gauge has a measurement accuracy of up to ±1mm, with a small blind spot of 50mm.
2. Smaller antenna size, meeting the needs of measurement for more working scenarios.
3. Multiple lens antennas, smaller emission angles, more concentrated energy, stronger echo signals, and higher reliability compared to other radar products under the same industrial and mining conditions.
4. Stronger penetration, allowing normal use even when adhesion and condensation occur.
5. Wider dynamic signal range, making measurements more stable for low dielectric constants.
6. Multiple measurement modes, selectable material level or empty height display, current output can be forward or backward.
7. Smaller measurement blind spots, achieving good results even for small tank measurements.
8. High signal-to-noise ratio, ensuring better performance even under fluctuating conditions.
9. High frequency is the ** choice for measuring solid and low dielectric constant media.

Technical Specifications

Item Specification
Product Model L329‑B804
Application Highly corrosive liquids, vapor, foam, stirring tanks
Measuring Medium Strong acid, strong alkali, corrosive liquid with vapor/foam/stirring
Measuring Range 0.1 m ~ 100 m
Process Connection Flange ≥ DN50
Process Temperature –40°C ~ 130°C
Process Pressure Item Specification
Antenna Size Measuring Media Highly corrosive liquids, steam, foam, high temperature & high pressure medium
Antenna Material Measuring Range 0.1 m ~ 100 m
Accuracy Process Connection Flange ≥ DN80
Protection Rating Process Temperature -40°C ~ 260°C (customizable up to 1100°C)
Center Frequency Process Pressure -0.1 MPa ~ 2.5 MPa
Emission Angle Antenna Size 76mm lens antenna (customized according to flange size)
Power Supply Antenna Material PTFE / Fully filled
Housing Material Measurement Accuracy ±1 mm
Signal Output Protection Rating IP67

Center Frequency 80 GHz

Launch Angle 3°

Power Supply Two-wire: DC24V

Four-wire: DC12~24V / AC220V

Housing Material Aluminum / Plastic / Stainless Steel

Signal Output Two-wire: 4~20mA / HART protocol

Four-wire: 4~20mA / RS485 MODBUS
