HACH Stainless Steel LDO Sensor Cap with IP65 Protection and 1/4 inch NPT Connection for Dissolved Oxygen Probes.
HACH Stainless Steel LDO Sensor Cap with IP65 Protection and 1/4 inch NPT Connection for Dissolved Oxygen Probes.
HACH Stainless Steel LDO Sensor Cap with IP65 Protection and 1/4 inch NPT Connection for Dissolved Oxygen Probes.
HACH Stainless Steel LDO Sensor Cap with IP65 Protection and 1/4 inch NPT Connection for Dissolved Oxygen Probes.
Specifications
Connectiontype :
1/4 inch NPT
Measurementrange :
0 to 1000 psi
Operatingtemperature :
-20°C to 85°C
Mountingtype :
Panel Mount, Wall Mount
Responsetime :
Less than 1 second
Accuracy :
±0.25% of full scale
Model Number :
5811200
Delivery Time :
2-3WEEK
Outputsignal :
4-20 mA, 0-10 V, Digital
MOQ :
1
Price :
39.9USD
Material :
Stainless Steel
Protectionrating :
IP65
Application :
Industrial, HVAC, Hydraulic Systems
Pressuretype :
Gauge, Absolute, Differential
Brand Name :
HACH
Powersupply :
24 V DC
Payment Terms :
T/T
Productname :
Pressure Measurement Instruments
Displaytype :
LCD Digital Display
Supply Ability :
1PC 2-3WEEK
Description

Product Overview

Item Specification
Model Number 5811200
Product Name IntelliCAL LDO Replacement Sensor Cap with iButton
Description Replacement luminescent DO cap for LDO101 optical dissolved oxygen probes
Measurement Principle Luminescent quenching (optical DO, no membrane, no electrolyte)
Compatible Probes LDO101 (Lab & Field versions)
Compatible Meters HQ2100, HQ2200, HQ4100, HQ4200, HQ4300; SC100, SC200, SC1000

Key Components

Item Specification
Contents Replacement LDO sensor cap + integrated iButton (stores calibration data)
Installation Screw‑on, direct replacement for LDO101 probe head

Performance & Life

Item Specification
Recommended Replacement Interval 12 months (typical; adjust for fouling)
Operating Temperature 0–50 °C (matches LDO101 probe)
Storage Dry, ambient temperature; avoid direct sunlight & organic solvents

Maintenance & Calibration

Item Specification
Calibration Data Stored in iButton; no recalibration required if valid
Tooling No special tools; hand‑tighten only
Cleaning Rinse with clean water; wipe gently with soft cloth; avoid abrasives

Physical

Item Specification
Material Chemically resistant polymer (cap body + luminescent layer)
Protection Rating IP68 (submersible with probe)

Applications

Item Specification
Typical Use DW, WW, surface water, aquaculture, industrial process water, environmental monitoring
