ASTM A572 Warehouse Steel Structure EN S355JR 82 Meters Modular Steel Buildings
ASTM A572 Warehouse Steel Structure EN S355JR 82 Meters Modular Steel Buildings
Specifications
size :
15-80 meters 、80-120 meters 、50-1000M
Feature :
Anti Earthquake、Antirust、Anti Corrosion
Performance :
Safety, water-proof, sound insulated,hear-preservation
Seismic Resistance :
Degree 8 Fortification
Wind Resistance Level :
Typhoon Level 12 (35m/s)
Design Service Life :
50 years
Type :
Light
Grade :
Q235B Q355B
Keyword :
Steel structure warehouse building prefab warehouse steel structure
Brand Name :
Shandong Xinghua Steel Structure
Model Number :
Steel plates, H-beams, angle steels, I-beams, channel steels, round pipes, square pipes, etc
Certification :
EN1900、Three-Body
Place of Origin :
China
MOQ :
10 tons
Price :
8000 yuan per ton
Payment Terms :
Advance payment plus full payment for delivery
Supply Ability :
Monthly supply capacity not less than 2000 tons .
Delivery Time :
After confirming the drawings, the shipment will be made within 20 days .
Packaging Details :
Bulk carriers, containers
Product Name :
Prefab Steel Structure
Standard :
GB EN ASTM
Description

Fast-Assembled Q355B Steel Large Warehouse - Economical Engineering Solution

prodnct deecrlption

Q355B high-strength steel fabricated large warehouse steel structure system, customized for modern logistics storage requirements. Portal frame structure enables an 82-meter max column-free span, suitable for large racking systems and automated equipment installation. Climate-adaptive design with integrated drainage/moisture barriers for rainy zones and high-reflectivity roof panels for indoor temperature reduction in hot climates.

Technical Specifications

Parameter

Specifications

Standards

Main Material

Q355B high-strength steel (equivalent to ASTM A572 Gr.50, EN S355JR)

GB/T 1591, ASTM A572, EN 10025

Ground Load

5-21 tons/m² (customizable based on storage requirements)

GB 50009, EN 1991

Span Range

15-82 meters (standard), 82-125 meters (custom design)

GB 50017, EN 1990, ASCE 7

Eave Height

8-20 meters (adjustable), compatible with high-level shelving systems

ISO 6781

Roof System

0.6mm aluminum zinc coated color steel plate, 100-200mm rock wool sandwich panel

ASTM A792, EN 10169

Key Advantages

1.Q355B high-strength steel provides exceptional load-bearing capacity for high-density rack systems

2.Featuring a rapid-construction system, a 10,000 square meter warehouse can be fully completed within just 6 months.

3.Modular expansion design, enabling flexible capacity upgrades to match your growing business needs.

4.Large-span column-free design, 30% higher storage space utilization.

Applications

1.Logistics distribution centers and regional distribution warehouses

2.Warehouses for industrial raw material and finished product storage

3.Cold chain logistics warehouses & temperature-controlled storage facilities

4.Port container yards & cargo transshipment stations

ASTM A572 Warehouse Steel Structure EN S355JR 82 Meters Modular Steel BuildingsASTM A572 Warehouse Steel Structure EN S355JR 82 Meters Modular Steel Buildings
