EN10025 Warehouse Steel Structure 100mm - 200mm Multi Storey Modular Buildings
EN10025 Warehouse Steel Structure 100mm - 200mm Multi Storey Modular Buildings
Specifications
Feature :
Anti Earthquake、Antirust、Anti Corrosion
Performance :
Safety, water-proof, sound insulated,hear-preservation
size :
15-80 meters 、80-120 meters 、50-1000M
Design Service Life :
50 years
Type :
Light
Product Name :
Prefab Steel Structure
Seismic Resistance :
Degree 8 Fortification
Brand Name :
Shandong Xinghua Steel Structure
Model Number :
Steel plates, H-beams, angle steels, I-beams, channel steels, round pipes, square pipes, etc
Certification :
EN1900、Three-Body
Place of Origin :
China
MOQ :
10 tons
Price :
8000 yuan per ton
Payment Terms :
Advance payment plus full payment for delivery
Supply Ability :
Monthly supply capacity not less than 2000 tons .
Delivery Time :
After confirming the drawings, the shipment will be made within 20 days .
Packaging Details :
Bulk carriers, containers
Grade :
Q235B Q355B
Keyword :
Steel structure warehouse building prefab warehouse steel structure
Standard :
GB EN ASTM
Wind Resistance Level :
Typhoon Level 12 (35m/s)
Description

High-Efficiency Q355B Steel Structure Large Warehouse, Budget-Friendly

prodnct deecrlption

Crafted from Q355B high-strength steel, this steel structure system for large warehouses is tailor-made for modern logistics storage needs. Boasting a portal frame structure, it offers a column-free space of up to 82 meters—ideal for large racking and automated equipment setup. Built to adapt to various climates, it features integrated drainage and moisture barriers for rainy regions, plus high-reflectivity roof panels that reduce indoor heat in hot areas.

Technical Specifications

Parameter

Specifications

Standards

Main Material

Q355B high-strength steel (equivalent to ASTM A572 Gr.50, EN S355JR)

GB/T 1591, ASTM A572, EN 10025

Roof System

0.6mm aluminum zinc coated color steel plate, 100-200mm rock wool sandwich panel

ASTM A792, EN 10169

Ground Load

5-21 tons/m² (customizable based on storage requirements)

GB 50009, EN 1991

Span Range

15-82 meters (standard), 82-125 meters (custom design)

GB 50017, EN 1990, ASCE 7

Eave Height

8-20 meters (adjustable), compatible with high-level shelving systems

ISO 6781

Roof System

0.6mm aluminum zinc coated color steel plate, 100-200mm rock wool sandwich panel

ASTM A792, EN 10169

advantages

1.Q355B high-strength steel, excellent load-bearing capacity for high-density racking.

2.Rapid-construction system: 10,000㎡ warehouse completed in 6 months.

3.Modular expandable design, flexible capacity increase for growing business demands.

4.Large-span column-free design, 30% higher storage space utilization.

Applications

1.Logistics/regional distribution warehouses

2.Industrial raw material finished product storage

3.Cold chain temperature-controlled storage warehouses

4.Port container yards cargo transshipment stations
