6-Layer Automotive HDI PCB: Advanced ADAS & Sensor Solution

Product Overview:

Our 6-layer HDI PCBs are engineered for high-performance automotive electronics, including ADAS modules, camera systems, and smart connectivity gateways. By utilizing a sophisticated 6-layer stack-up with precision micro-via technology, we enable high-speed data processing and superior signal isolation in a space-saving design. These boards are built with specialized materials to withstand harsh automotive environments, ensuring stability under extreme thermal cycles and mechanical stress. Designed for zero-defect reliability, our HDI solutions provide the robust, high-bandwidth core necessary for the next generation of intelligent and safe vehicle accessories.

Key Selling Points:

• Auto-Grade Reliability: Engineered for extreme vibration and heat.

• High Signal Integrity: 6-layer EMI shielding for ADAS & RF modules.

• Compact Density: Precision HDI routing for slim automotive housings.

Engineering Support: DFM (Design for Manufacturing) check before production.

Testing: Flying Probe Test, Fixture Test, Impedance Control Test, Thermal Stress Test.

“ Instant PCB(1-38 layers)”--PCBgate

PCBgate is a professional PCB manufacturer providing high-quality printed circuit boards for global electronics industries.

We are capable of manufacturing a wide range of PCB types to meet different application requirements, including:FR-4 PCBs,ceramic PCBs,carbon oil PCBs,Aluminum PCBs,Flexible & Rigid-Flex PCBs.

We specialize in 6-layer Automotive Grade HDI PCB manufacturing, providing the perfect balance between signal isolation and space efficiency. By using Laser Direct Imaging (LDI) and high-speed laser drilling, we achieve the precise registration required for your advanced 1+N+1 and 2+N+2 stack-up designs.

This 6-layer structure is ideal for ADAS controllers, HUD displays, and smart telematics. We ensure 100% E-test and AOI inspection to guarantee that every board meets the highest industrial standards for voltage safety and operational performance.

We support HDI PCB prototypes, small-batch production, and mass production to meet different customer requirements, helping you accelerate your product's time-to-market.

Our PCB manufacturing capability includes:

• Fine Line Technology: Min. Trace/Space down to 0.075mm / 0.075mm

• Blind & Buried Vias: Professional via-in-pad and resin filling processes

• High-End Materials: High-TG, Low-Loss, and Halogen-free laminates

• Surface Finishes: ENIG, ENEPIG, and OSP for superior soldering

• Complex Stack-ups: Multilayer HDI integration up to 20+ layers

• Rigorous Testing: AOI, Micro-sectioning, and Impedance Control

Attention: pictures are for reference only. The specific products are subject to the original factory model.

Standard Packaging: Inner Vacuum Packaging + Outer Carbon Box.

Delivery Partners: EMS,DHL,SF-express, FedEx, UPS or Sea/Air Freight for bulk orders.

• 15 years of experience in PCB manufacturing.

• Advanced Equipment: Equipped with high-speed CNC drilling machines and AOI testing lines.

• Professional engineering support

• Fast prototype delivery

• Global customers from Europe, USA and Asia

• Own Global Supply System.

• Fast and safe way by EMS/DHL/SF-express/Fedex,etc.

• New styles updating everyday and MOQ for all the styles;
