12-Layer Defense-Grade HDI PCB | Ultra-Reliable Aerospace Solution

Product Overview:

Our 14-layer HDI PCBs are the ultimate interconnect solution for next-generation defense and aerospace hardware. Engineered with high-order Any-Layer technology, these boards enable the massive integration of multi-core processors and high-speed memory within extremely confined spaces. Designed for zero-failure performance, each board features superior electromagnetic isolation and thermal management to ensure operational stability under severe environmental stress. Whether for tactical communication or sophisticated satellite systems, our 14-layer HDI solutions provide the ruggedized, high-bandwidth foundation necessary for the world’s most advanced mission-critical technology

Key Selling Points:

• Supreme Reliability: Engineered for zero-failure in combat & space.

• Ultra-Density: 14-layer Any-layer tech for advanced Strategic-Grade AI.

• Elite Materials: Low-loss substrates for high-speed signal purity.

Engineering Support: DFM (Design for Manufacturing) check before production.

Testing: Flying Probe Test, Fixture Test, Impedance Control Test, Thermal Stress Test.

“ Instant PCB(1-38 layers)”--PCBgate

PCBgate is a professional PCB manufacturer providing high-quality printed circuit boards for global electronics industries.

We are capable of manufacturing a wide range of PCB types to meet different application requirements, including:FR-4 PCBs,ceramic PCBs,carbon oil PCBs,Aluminum PCBs,Flexible & Rigid-Flex PCBs.

We specialize in 14-layer High-Order Strategic-Grade HDI PCB manufacturing, providing the perfect balance between extreme circuitry density and mission-critical durability. By using Laser Direct Imaging (LDI) and high-speed laser drilling, we achieve the precise registration required for your advanced 0.3mm pitch BGA and Any-Layer stack-up designs.

This 14-layer structure is ideal for satellite avionics, phased-array radars, and tactical encryption systems. We ensure 100% E-test and AOI inspection to guarantee that every board meets the highest industrial standards for signal stability and performance.

We support HDI PCB prototypes, small-batch production, and mass production to meet different customer requirements, helping you accelerate your product's time-to-market.

Our PCB manufacturing capability includes:

• Fine Line Technology: Min. Trace/Space down to 0.075mm / 0.075mm

• Blind & Buried Vias: Professional via-in-pad and resin filling processes

• High-End Materials: High-TG, Low-Loss, and Halogen-free laminates

• Surface Finishes: ENIG, ENEPIG, and OSP for superior soldering

• Complex Stack-ups: Multilayer HDI integration up to 20+ layers

• Rigorous Testing: AOI, Micro-sectioning, and Impedance Control

Attention: pictures are for reference only. The specific products are subject to the original factory model.

Standard Packaging: Inner Vacuum Packaging + Outer Carbon Box.

Delivery Partners: EMS,DHL,SF-express, FedEx, UPS or Sea/Air Freight for bulk orders.

• 15 years of experience in PCB manufacturing.

• Advanced Equipment: Equipped with high-speed CNC drilling machines and AOI testing lines.

• Professional engineering support

• Fast prototype delivery

• Global customers from Europe, USA and Asia

• Own Global Supply System.

• Fast and safe way by EMS/DHL/SF-express/Fedex,etc.

• New styles updating everyday and MOQ for all the styles;
