Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Specifications
Brand Name :
PUNAISGD
Model Number :
ASU-24B1.3
Certification :
CE/ROHS/ISO9001
Place of Origin :
Guangdong, China
MOQ :
1km
Price :
negociate
Payment Terms :
T/T,Western Union
Supply Ability :
100000
Delivery Time :
7days
Packaging Details :
wooden drum
Name :
ADSS Fiber Optic Cable
Type :
ASU-24B1.3
Application :
Telecom Comunication
Strength member :
frp *2pcs
Jacket color :
Black Color/Others
Packing :
Wooden Roller
Number of conductors :
8-24
Fiber type :
G652D
Outer sheath :
PE/AT,AT/PE,PE
Span :
120
Out diameter :
8mm
Description
ADSS Fiber Optic Cable ASU80 Fiber Telecomunicaciones Cable Optical 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Proven all-dielectric loose tube construction Immune to electromagnetic fields Fast, one-step installation Integrated FRP strength elements Round cable profiles minimize wind and ice loading
PRODUCT SPECIFICATIONS
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Optical Characteristics
Cable Type
Fiber Count
Cable Diameter (mm)
Cable Weight (kg/km)
Tensile Strength long/short term (N)
Crush Resistance long/short term (N)
Bending Radius Static/Dynamic (mm)
ASU
2-12
7.0
60
600/1500
300/1000
10D/20D
GYXTW
14-24
8.0
72
600/1500
300/1000
10D/20D

Item
Unit
Specification
Fier Tyoe
G652D
G652D
Mode filed Diameter
1310nm
μm
9.2±0.4
1550nm
μm
10.4±0.8
Cladding diameter
μm
125.0±0.1
Cladding non-circularity
%
≤1.0
Core/cladding concentricity error
μm
≤0.5
Coating diameter
μm
245±7
Coating/cladding concentricity error
μm
≤12
Cable cut-off wavelength
μm
≤1260
Attenuation Coefficient
1310nm
db/km
≤0.36
1550nm
db/km
≤0.22
Proof stress level
kpsi
≥100
Note: Other parameters meet standard ITU-T G.652
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Our Factory
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
Telecom Comunication Fiber Optic Cable ASU80 6 12 24 Hilos Airfiber ADSS Optical Cable
FAQ
1. Why choose us?
We are manufacturer, Located in Guangzhou, China, started from 2011, sell to Domestic Market(100.00%). There are total about 11-50
people in our factory.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.Can you send products to my country?
Sure, we can. If you do not have your own ship forwarder, we can help you.

4. Can you do OEM for me?
We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you.

5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,PayPal,Western Union,Escrow;
Language Spoken:English,Chinese
