0.71 Inch Circle TFT Display Screen Small TFT Display 160x160
0.71 Inch Circle TFT Display Screen Small TFT Display 160x160
Specifications
Brand Name :
Limito
Model Number :
LB071R-PF01
Place of Origin :
China
Certification :
RoSH, Reach
MOQ :
10pcs
Price :
Negotiable
Packaging Details :
Cartons, Capboard, EPE, Blister Tray.
Delivery Time :
3-5days
Payment Terms :
T/T, Paypal
Supply Ability :
7kk/M
Diagonal Screen Size :
0.71
Drive IC :
GC9D01N
Interface :
4 Line SPI
Operating Temp :
-20℃~ + 70℃
Storage Temp :
-30℃~+ 80℃
Description

0.71 Inch Circle TFT Display Screen Small TFT Display 160x160

1.Mechanical Drawing

0.71 Inch Circle TFT Display Screen Small TFT Display 160x160

2.Basic specification

Part Name:
OLED Display Module
Limito Part ID:
LB071R-PF01
Display Mode:
Normally black
Resolution
160(H)RGB x160(V)
Pixel pitch
0.1125(H) x 0.1125(V)
Active area
18(H) x18(V)
Module size
20.21(H) x 22.35(V) x1.86 (D)
Pixel arrangement
RGB Vertical stripe
Display Colors
262K
Luminance(cd/m2)
400 (TYP) Cd/m2
Viewing Direction
All View

LB071R-PF01 is a 160RGBX160 dot-matrix TFT LCD module. This module is composed of a TFT LCD
Panel, driver ICs, FPC and a Backlight unit.

LIMITO OLED Benefits:

High Contrast Ration(10,000:1)

Free Viewing Angle

Fast Response Time(<15us)

Thinner &Lighter&Durable

Wide operation Temperature-40°c~+85°c

Self-emitting,No need of backlight

LIMITO OLED Application :

Industrial: Mearusring& meter,OA Equipment,POS&Server Card Reader,Door Security,USB Key

Communication:Mobile Phone,Bluetooth Device,Router,Set-Top Box

Automotive:Head Up display, Car Audio, Speed Detector, ECT, Timer, Climate Control, Dashboard

PC peripheral: Keyboard, Mouse,Printer,Scanner,NAS, Digital Pen

Medical:Glucose Meter,Oximeter,Blood-pressure Meter,Beauty&Cosmetic Equipment

Consumer:IoT,E-Cigarette,Wearable Device,Remote Controller,Game Machine,Digital Camera,Audio Video Equipment
