Specifications
Brand Name :
OUCO
Model Number :
OUCO-CWI-180GB
Certification :
CE, ISO9001:2008, SGS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 sets/year
Delivery Time :
2 months
Packaging Details :
Nude
Product Name :
Durable Barrel Injection Molding Machine Equipped With Damped Distributor CWI-180GB
Type :
Automation
Function :
Plastic Parts Production
Motor :
Servo Energy Saving
Color :
Support customization
Stable Performance :
Short Cycle Time
Clamping Way :
Hydraulic
Transport Package :
FCL
Description

Durable Barrel Injection Molding Machine Equipped With Damped Distributor CWI-180GB

OUCO plastic machine adopts American original imported Vickers directional proportional double control valve and ultra-precision Northman hydraulic valve to improve the response speed and control accuracy, and adopts damping type distributor to greatly improve the life of the machine

Product Advantages

-Eight section of PID control functions, heating each section of the barrel separately, improve plasticisation and prevent overheating

-Output of the 48 point digital transistor with shot circuit and over load protects function

-Clamping, injection and ejection strokes are controlled precisely by the linear transducers

-Automatic mould thickness adjustment

-Five stages control on mould opening, closing and injection makes the operation more stable and precise

Parameters

MODEL CWI-180GB
CLAMPING UNIT clamping force (kN) 1800
Tie bar distance W×L (mm) 520*520
Max.Daylight(mm) 500
Max. mold thickness (mm) 550
Min. mold thickness(mm) 200
Platen Dimensions W×L (mm) 755x755
Ejector Stroke(mm) 140
Ejector Force(Kn) 53
Ejector Quantily 5
Injection unit 650D 860D
Injection Unit Screw Diameter(mm) 40 45 45 50
Screw L/D ratio 23.6 21 23.3 21
Theoretical injection volume (cm3) 251 318 357 441
Shot Weight (PS) g 231 292 328 406
Injection Pressure(MPa) 256 202 232 188
Injection Speed (mm/s) 121 99
Injection Rate (cm3/s) 152 192 157 194
Screw Speed (rpm) 300 195
Other Motor Power (Kw) 24
pump capacity(L/min) 138
Heater Power (Kw) 10.9 13.3
Machine Weight (kg) 6.5
Machine size L×W×H (mm) 5455x1620x1820
