Specifications
Brand Name :
OUCO
Model Number :
OUCO-HS-530T
Certification :
ISO9001:2008,CE,TUV
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
2500 Set/Sets per Year
Delivery Time :
35 work days
Price :
Negotiable
Packaging Details :
shipping container
Product :
Small Footprint Plastic Fully Automatic injection Mold Machine HS Series
Power :
50.7 kW
Screw diameter :
180 mm
Open Stroke :
1850 mm
Applicable Industries :
Food & Beverage Factory, Home Use
Core Components :
Pump
Style :
Style
Condition :
New
Automatic :
Yes
Description

Small Footprint Plastic Injection Mold Machine HS Series

Our HS series enables you to increase your production efficiency to the maximum. Leading technology and performance, central locking toggle .Smallest footprint, most energy-efficient drive technology large option portfolio, maximum flexibility and uptime. All at an attractive package price.

CWI-110GB CWI-150GB
机型 CWI-110GB CWI-150GB
合模装置 锁模力 Kn clamping force (kN) 1100 1500
拉杆间距 mm Tie bar distance W×L (mm) 420×420 470×470
开模最大开距 mm Clamping Stroke 400 450
最大模厚 mm Max. mold thickness (mm) 450 520
最小模厚 mm Min. mold thickness(mm) 150 170
模板尺寸 mm Platen Dimensions W×L (mm) 605×605 680×680
顶出长度 mm Ejector Stroke 110 140
顶出力 Kn Ejector Force 38 53
顶针数 Ejector Quantily 5 5
310D 420D 420D 650D
注射装置 螺杆直径 mm Screw Diameter(mm) 28 32 35 35 40 35 40 40 45
螺杆长径比 Screw L/D ratio 23.4 23 21 24 21 24 21 23.6 21
理论射胶容积 cm3 Theoretical injection volume (cm3) 89 117 140 163 214 163 214 251 318
注射重量 (PS)g Shot Weight 81 108 129 150 196 150 196 231 292
注塑压力 Mpa Injection Pressure(MPa) 306 234 204 256 196 256 196 240 190
注射速度 mm/s Injection Speed 129 101 126 100
注塑速率 cm3/s Injection Rate (cm3/s) 76 99 119 93 121 116 151 138 175
螺杆最大转速 rpm Screw Speed 330 250 300 220
其他 油泵电机功率 Kw Motor Power 16 20
油泵排量 L/min 88 110
电热功率 Kw Heater Power 7.11 8.91 8.91 10.9
机器净重 ton Machine Weight (kg) 4.2 5.2
机器尺寸(长×宽×高) mm Machine size L×W×H (mm) 4255×1430×1690 5095×1500×1745

TUV Footprint Small Injection Molding Machine HS Series Injection Mold

Main Features

Due to the high wastage of clamping force in conventional constructions, efficiency is only 80 - 85% and there is significant distortion of the moving platen, resulting in flying edges and wasted material and labour in trimming the flying edges.
OUCO has designed a central clamping structure that ensures 100% clamping force is used.
Not only does it reduce the possibility of flashing, but it also saves flash trim work.
Saves 2-5% of material while providing good protection for the mould, platens and tie bars.
10-20% longer opening stroke.

Application

TUV Footprint Small Injection Molding Machine HS Series Injection Mold

Advantage of Small Footprint Plastic Fully Automatic injection Mold Machine HS Series
1.Cost is less by same mold opening length
2.Energy saving with electromagnetic heaters and frequency converters
3.Double servo motor power control adopts the latest confluence technology
4.Safe and intelligent mold protection design
