160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
160 T High Speed Mini Plastic Injection Moulding Machines For Basket Mold
Specifications
Brand Name :
OUCO
Model Number :
OUCO-H160T
Certification :
CE, ISO9001:2008, SGS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 sets/year
Delivery Time :
2 months
Packaging Details :
Nude
Product Name :
160 T High-speed Mini Injection Machine for Basket Mold
Type :
Automation
Function :
Plastic Parts Production
Motor :
Servo Energy Saving
Color :
Support customization
Stable Performance :
Short Cycle Time
Clamping Way :
Hydraulic
Transport Package :
FCL
Description

160 T High-speed Mini Injection Machine for Basket Mold

Product advantages:

1. Using can bus and EtherCAT bus communication, so that the computer system is completely digital control.

2. Special control module is used for temperature control. The precision can reach 1 degree.

3. With power monitoring function, it can monitor the current energy consumption in the production process.

4. Special single-cylinder structure greatly reduces the amount of oil return in the high-speed injection process. At the same time reduce the return oil pressure, thereby increasing the machine's injection acceleration.

5. When using graphite steel bushing and thin oil lubrication, the bent elbow connecting rod and guide rod have better bearing resistance and wear resistance. This machine has a longer service life.

6. Controlled by proportional directional valve, it can accelerate movement quickly. When running at high speed, it can control the opening position stably and precisely.

7. The hydraulic system is controlled by double servo drive. It has the advantages of high efficiency; energy saving and low noise. At the same time, it can realize the synchronous function of mold opening and loading.

Product Parameters

TECHNICAL PARAMETER TABLE A B
Screw diameter mm 40 45
Screw L/D ratio L/D 22 20
Injection capacity in theory cm3 232 294
Injection weight (Ps) g 211 268
Injection pressure MPa 237 187
Injection speed mm/s 250
Plasticizing Capacity g/s 28 40
Screw speed r/min 400
Clamping force kN 1600
Opening stroke mm 420
Max mold height mm 530
Min mould height mm 150
Space between tie-bar mm 520x470
Ejector force kN 62
Ejector stroke mm 130
Ejector No n 5
Pump pressure MPa 17.5
Motor power KW 37
Heating power KW 13.55
Machine dimension m 5.37x1.50x1.80
Machine weight t 7.0
Oil tank capacity L 280


Detail Pictures
