SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
Specifications
Brand Name :
OUCO
Model Number :
OUCO-H350T
Certification :
CE, ISO9001:2008, SGS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 sets/year
Delivery Time :
2 months
Packaging Details :
Nude
Product Name :
350 T Hydeaulic\Electronic Injection Moulding Machine in India
Type :
Automation
Function :
Plastic Parts Production
Motor :
Servo Energy Saving
Color :
Support customization
Stable Performance :
Short Cycle Time
Clamping Way :
Hydraulic
Transport Package :
FCL
Description

350 T HydeaulicElectronic Injection Moulding Machine in India

Product advantages

1. Using can bus and EtherCAT bus communication, so that the computer system is completely digital control.

2. Special control module is used for temperature control. The precision can reach 1 degree.

3. With power monitoring function, it can monitor the current energy consumption in the production process.

4. Special single-cylinder structure greatly reduces the amount of oil return in the high-speed injection process. At the same time reduce the return oil pressure, thereby increasing the machine's injection acceleration.

5. When using graphite steel bushing and thin oil lubrication, the bent elbow connecting rod and guide rod have better bearing resistance and wear resistance. This machine has a longer service life.

6. Controlled by proportional directional valve, it can accelerate movement quickly. When running at high speed, it can control the opening position stably and precisely.

7. The hydraulic system is controlled by double servo drive. It has the advantages of high efficiency; energy saving and low noise. At the same time, it can realize the synchronous function of mold opening and loading.

Product Parameters

TECHNICAL PARAMETER TABLE A B
Screw diameter mm 55 60
Screw L/D ratio L/D 24 22
Injection capacity in theory cm3 582 692
Injection weight (Ps) g 529 630
Injection pressure MPa 175 148
Injection speed mm/s 320
Plasticizing capacity g/s 80 97
Screw speed r/min 400
Clamping force kN 3500
Opening stroke mm 630
Max mold height mm 650
Min mould height mm 250
Space between tie-bar mm 710x660
Ejector force kN 125
Ejector stroke mm 180
Ejector No n 13
Pump pressure MPa 17.5
Motor power KW 37+37
Heating power KW 20.3
Machine dimension m 7.20x1.88x2.12

Detail Pictures

SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine

SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine

Company Profile

SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine

SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine

SGS Electric Injection Moulding Machines Hydeaulic 350 Ton Injection Molding Machine
