Broadcom HCPL 354 000E optocoupler featuring UL CSA and IEC EN certifications in compact SMD package
Broadcom HCPL 354 000E optocoupler featuring UL CSA and IEC EN certifications in compact SMD package
Specifications
Fall time :
3us
Rise time :
4us
Output Current :
50mA
Vce Saturation(VCE(sat)) :
100mV@20mA,1mA
Operating Temperature :
-55℃~+100℃
Load Voltage :
35V
Reverse Voltage :
-
Current transfer ratio :
20%;400%
Forward Current(If) :
50mA
Pd - Power Dissipation :
170mW
Number of Channels :
-
Load Type :
Phototransistor
Input type :
AC,DC
Isolation Voltage(Vrms) :
3.75kV
Description :
50mA 100mV@20mA,1mA 35V AC,DC SMD-4P Transistor, Photovoltaic Output Optoisolators RoHS
Mfr. Part # :
HCPL-354-000E
Model Number :
HCPL-354-000E
Package :
SMD-4P
Description

Product Overview

The Broadcom HCPL-354 is an AC input phototransistor optocoupler designed for space-saving applications. It features a phototransistor optically coupled to two inverse parallel LEDs, allowing direct operation with AC input current. Packaged in a 4-pin mini-flat SMD with a 2.0-mm profile, it offers a 30% smaller volume than conventional DIP types. The HCPL-354 provides an input-output isolation voltage of 3750 Vrms, a typical response time of 4 s, and a minimum Current Transfer Ratio (CTR) of 20% at 1 mA input current. It is suitable for detecting or monitoring AC signals, programmable controllers, AC/DC-input modules, and AC line/digital logic isolation.

Product Attributes

  • Brand: Broadcom
  • Package Type: 4-pin mini-flat SMD
  • Profile: 2.0 mm
  • Certifications: UL approved, CSA approved, IEC/EN 60747-5-5 approved
  • ESD Handling: Normal static precautions recommended
  • Application Restrictions: Not for , aerospace, or AEC-Q100 qualified automotive applications.

Technical Specifications

Parameter Symbol Min. Typ. Max. Units Test Conditions
Storage Temperature TS 55 150 C
Ambient Operating Temperature TA 55 100 C
Lead Solder Temperature (10s) Tsol 260 C (1.6 mm below seating plane)
Average Forward Current IF 50 mA
Input Power Dissipation PI 70 mW
Collector Current IC 50 mA
Collector-Emitter Voltage VCEO 35 V
Emitter-Collector Voltage VECO 6 V
Collector Power Dissipation PC 150 mW
Total Power Dissipation Ptot 170 mW
Isolation Voltage (AC for 1 min) Viso 3750 Vrms (RH = 40 ~ 60%)
Forward Voltage VF 1.2 1.4 V IF = 20 mA
Terminal Capacitance Ct 30 250 pF V = 0, f = 1 kHz
Collector Dark Current ICEO 100 nA VCE = 20V, IF = 0
Collector-Emitter Breakdown Voltage BVCEO 35 V IC = 0.1 mA, IF = 0
Emitter-Collector Breakdown Voltage BVECO 6 V IE = 10 A, IF = 0
Collector Current IC 0.2 4 mA IF = 1 mA
Current Transfer Ratio (CTR) CTR 20 400 % VCE = 5V, IF = 1 mA
Collector-Emitter Saturation Voltage VCE(sat) 0.1 0.2 V IF = 20 mA, IC = 1 mA
Isolation Resistance Riso 5 1010 1 1011 DC 500V, 40 ~ 60% RH
Floating Capacitance Cf 0.6 1 pF V = 0, f = 1 MHz
Response Time (Rise) tr 4 18 s VCE = 2V, IC = 2 mA
Response Time (Fall) tf 3 18 s RL = 100
Rank Mark CTR (%) Conditions
A 50 ~ 150 IF = 1 mA, VCE = 5V, TA = 25C
No Mark 20 ~ 400 IF = 1 mA, VCE = 5V, TA = 25C
Part Number Package Surface Mount Gull Wing Tape and Reel Quantity Option Rank
HCPL-354-000E SO-4 X X X 3000 pieces per reel RoHS Compliant '0' (20%<CTR<400%)
HCPL-354-00AE SO-4 X X X 3000 pieces per reel RoHS Compliant 'A' (50%<CTR<150%)
HCPL-354-060E SO-4 X X X 3000 pieces per reel IEC/EN 60747-5-5 Safety Approval, RoHS Compliant '0' (20%<CTR<400%)
HCPL-354-06AE SO-4 X X X 3000 pieces per reel IEC/EN 60747-5-5 Safety Approval, RoHS Compliant 'A' (50%<CTR<150%)

2410121837_Broadcom-HCPL-354-000E_C7466699.pdf
