Optocoupler With High AC Isolation Voltage VISHAY TCMD4000 Suitable For Industrial And Communication
Optocoupler With High AC Isolation Voltage VISHAY TCMD4000 Suitable For Industrial And Communication
Specifications
Output Current :
80mA
Rise time :
300us@10mA,100Ω
Fall time :
-
Vce Saturation(VCE(sat)) :
1V@5mA,20mA
Operating Temperature :
-40℃~+100℃
Load Voltage :
35V
Reverse Voltage :
6V
Current transfer ratio :
600%
Voltage - Forward(Vf) :
1.25V
Forward Current(If) :
60mA
Number of Channels :
4
Load Type :
Darlington Transistor
Input type :
DC
Isolation Voltage(Vrms) :
3.75kV
Description :
80mA 1V@5mA,20mA 35V 6V 1.25V DC SOP-16-4.4mm Transistor, Photovoltaic Output Optoisolators RoHS
Mfr. Part # :
TCMD4000
Model Number :
TCMD4000
Package :
SOP-16-4.4mm
Description

TCMD1000 / TCMD4000 Optocoupler

The TCMD1000 and TCMD4000 are high-gain, single/quad channel optocouplers featuring a photodarlington output. Encased in a low-profile, half-pitch mini-flat package, these devices offer AC isolation test voltage of 3750 VRMS and low coupling capacitance. They are suitable for applications requiring high safety standards, such as programmable logic, modems, answering machines, and general-purpose interfacing.

Product Attributes

  • Brand: Vishay Semiconductors
  • Certifications: UL1577 (file no. E76222), CSA 22.2 bulletin 5A, DIN EN 60747-5-5 (VDE 0884-5), FIMKO, BSI
  • Material Categorization: Refer to www.vishay.com/doc?99912 for compliance definitions.

Technical Specifications

ModelPackageCTR (%) (min.)AC Isolation Test Voltage (RMS)Input Reverse Voltage (max.)Input Forward Current (max.)Output Collector Emitter Voltage (max.)Output Collector Current (max.)Total Power Dissipation (max.)Operating Ambient Temperature Range
TCMD1000SOP-46003750 VRMS6 V60 mA35 V80 mA250 mW-40 to +100 C
TCMD4000SOP-16, quad channel6003750 VRMS6 V60 mA35 V80 mA250 mW-40 to +100 C

2410121757_VISHAY-TCMD4000_C142642.pdf
