Rotary Clamp Cylinder Air Cylinder Welding Clamps ISO9001 Certification
Rotary Clamp Cylinder Air Cylinder Welding Clamps ISO9001 Certification
Rotary Clamp Cylinder Air Cylinder Welding Clamps ISO9001 Certification
Rotary Clamp Cylinder Air Cylinder Welding Clamps ISO9001 Certification
Specifications
Brand Name :
Jiayan
Model Number :
ACK
Certification :
ISO9001:2008
Place of Origin :
Dongguan China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union,PayPAL
Supply Ability :
1000 sets per week
Delivery Time :
7 days
Packaging Details :
poly bag and carton box
Material :
Aluminium Alloy
Type :
Standard
Structure :
Rotary Cylinder
Power :
Pneumatic
Maximum Stroke :
15mm
Shaft Diameter: :
25mm-63mm
Acting Type: :
Double acting
Working Media :
Cleaned Air
Working Pressure :
0.1-0.9Mpa
Working Temperature :
-5~70℃
Port size: :
M5X0.8
Working Speed: :
30~500 mm/sec
Rotary Stroke :
11-15mm
Clamping Stroke :
11-15mm
Description

Pneumatic Rotary Swing Twist Clamping Air Cylinder Welding Clamps

Specifications

Bore Size(mm) 25 32 40 50 63
Working Type Double Acting
Working Media Cleaned Air
Working Pressure 0.15~0.95Mpa
Working Temperature 0~60℃
Working Speed 30~500mm/sec
Rotary Stroke 11mm 13mm 15mm
Down Stroke 11mm 13mm 15mm
Rotation Angle 90° can be customized(0°, 45°, 60°)
Direction of Rotation Turn left(from right to left)-L; turn right(from left to right)-R
Buffering Rubber Cushion
Port Size M5X0.8 M5X0.8
Lubrication

Freely supply
