Specifications
Brand Name :
Jiayan
Model Number :
SDMA/SDMB
Certification :
ISO9001:2008
Place of Origin :
Dongguan China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, , T/T, Western Union, Paypal
Supply Ability :
300 sets per week
Delivery Time :
7 days
Packaging Details :
poly bag and carton box
Material :
Carbon Steel
Mounting Type :
axial manifold type
Max Operation Force :
140kg/cm2
Min. Operation Force :
5 kg/cm2
flow rate :
8-100mm/sec
Acting Type :
Double Acting
Warranty :
1 year (change new one for free)
Description

Axial Front Manifold Type and Rear Manifold Type Push Pull Hydraulic Cylinder Simple Mounting Machine Cylinder

Ordering Code

CHTB - SDMA 32×20 N

1 2 3 4 5

1 Series CHTB
2 Mounting type SDMA:Axial front manifold type
SDMB:Axial back manifold type
3 Bore of Cylinder Φ20 , Φ25 , Φ32 , Φ40 , Φ50 , Φ63 , Φ80
4 Standard stroke Please refer to the <stroke specification>
5 Rod end type

N: Female thread N W:Male thread W

Hydraulic Cylinder Stroke Specifications

Square Push Pull Hydraulic Cylinder Axial Front Manifold Type Rear Manifold Type

Square Push Pull Hydraulic Cylinder Axial Front Manifold Type Rear Manifold Type

Pressure

Bores of Cylinde Dia.of Piston Area (cm2) OPERATION PRESSURE(kgf/cm2) Temperature

Square Push Pull Hydraulic Cylinder Axial Front Manifold Type Rear Manifold Type

Square Push Pull Hydraulic Cylinder Axial Front Manifold Type Rear Manifold Type

CHTB Hydraulic Cylinder Axial manifold type SDMA/SDMB

Square Push Pull Hydraulic Cylinder Axial Front Manifold Type Rear Manifold Type
